Digital Projection
E-Vision 8000 series
Menu Sub Menus and Controls

LAMPS

Mode
Dual, Single
Power
Normal, Custom Power, Eco
High Altitude
Custom Power
Lamp Status
Lamp Time

ALIGNMENT

Rear Projection
Ceiling Mode
Lens Control
Lens Memory
Load Memory
Save Memory
Center Lens
Warp
Keystone
Rotation
Pincushion/Barrel
Top Left Corner, Top Right, Bottom Left, Bottom Right
Custom Warp
Reset (all warp settings)
Blanking
Edge Blend
Edge Blend
Blend Width
Black Level Uplift
Select Area
Adjust Width
Reset (all edge blend settings)
Align Pattern
Rev A April 2012
Off, On
80-100%
Information Only: Lamp 1 On, Off
Information Only: Lamp 1 Hrs Lamp 2 Hrs
Off, On
Off, On
Shift, Zoom/Focus
Memory 1-10
Memory 1-10
Press to execute
ENTER
Horizontal, Vertical
Press ENTER
Top, Bottom, Left, Right, Reset (all blanking settings)
Off, On
Top, Bottom, Left, Right
Top, Bottom, Left, Right
All, Red, Green, Blue
Press
Off, On
MENU MAP
Lamp 2 On, Off
to execute
ENTER to execute
Operating Guide
Notes
Some of the information in this menu
map is summarised. See the actual
menu on the projector for full detail.
Some menu options and controls
may not be available due to settings
in other menus. These will be
shaded grey on the actual menu.
Where it would be helpful, some
menu options are described in more
detail earlier in this operating guide.
Page Op_23
