Digital Projection
E-Vision 8000 series
Signal Inputs and Outputs
3G-SDI IN
•
Connect a 3G-SDI cable to the left hand SDI BNC.
3G-SDI OUT
•
Connect a 3G-SDI cable to the right hand SDI BNC, to distribute the signal to another
projector.
HDMI
•
Connect a HDMI cable to the HDMI connector.
DVI-D
•
Connect a DVI-D cable to the DVI connector.
VGA
•
If necessary, use the VGA Setup
see the Operating Guide.
•
Set in the menu to
Color Space INPUT
COMPONENT
RGBHV, RGsB or RGBS
•
Set Color Space in the INPUT menu to
YPbPr or YCbCr
•
Set Color Space in the INPUT menu to
S-Video
•
Connect an S-Video cable to the 4-pin mini-DIN.
Video
•
Connect a composite video cable to the single RCA phono connector.
•
Set Video Standard in the INPUT
Rev A April 2012
controls in the PICTURE menu. For more information,
or .
Auto RGB-PC
Auto or RGB-Video .
YPbPr or YCbCr .
menu to Auto , PAL , SECAM , or NTSC
SIGNAL INPUTS AND OUTPUTS
3G-SDI
IN OUT
OPTION
BOARD
For a complete listing of pin
configurations for all signal and
control connectors, see Wiring
Details later in this Guide.
HDMI
DVI-D
VGA COMPONENT
Connection Guide
Notes
S-VIDEO VIDEO
