Summary of Contents for Digital Projection E-Vision Laser 13000 WU Series
- Page 1 E-Vision Laser 13000 WU Series High Brightness Digital Video Projector INSTALLATION & QUICK START GUIDE CONNECTION GUIDE OPERATING GUIDE REFERENCE GUIDE Rev A June 2019 119-946A...
-
Page 2: About This Document
Product revision Because we at Digital Projection continually strive to improve our products, we may change specifications and designs, and add new features without prior notice. Updates may be available online. Please visit the Digital Projection website for all latest documents. -
Page 3: Laser Information
Laser information Digital Projection Ltd. E-Vision Laser 13000 WU Series Laser information Notes C o m p l i e s w i t h F D A p e r f o r m a n c e s t a n d a r d s f o r l a s e r p r o d u c t s e x c e p t f o r d e v i a t i o n s p u r s u a n t t o L a s e r N o t i c e N o . -
Page 4: Light Hazard Warning
Digital Projection Ltd. E-Vision Laser 13000 WU Series Light Hazard Warning Light Hazard Warning Notes The hazard distance is the distance measured from the No direct exposure to the projection lens at which the intensity or energy per unit of... -
Page 5: Introduction
Digital Projection Ltd. E-Vision Laser 13000 WU Series Introduction Notes Congratulations on your purchase of this Digital Projection product. Your projector has the following key features: WUXGA projector. Support for Frame Sequential and Dual Pipe 3D formats. HDBaseT® for transmission of uncompressed High Definition Video up to 100 m from the source. -
Page 6: Table Of Contents
Digital Projection Ltd. E-Vision Laser 13000 WU Series Contents Contents Notes About this document Selecting an input signal Symbols used in this document Selecting a test pattern Product revision Adjusting the lens Legal notice Lens menu Laser information Remote control... - Page 7 Contents Digital Projection Ltd. E-Vision Laser 13000 WU Series Notes Exiting menus and closing the OSD Overscan Inside a menu Blanking Accessing sub menus Keystone Executing commands Keystone example Editing projector settings Keystone settings Using a slider to set a value...
- Page 8 Digital Projection Ltd. E-Vision Laser 13000 WU Series Contents Notes Power on / off Positioning the image Clock adjust Aspect ratios explained OSD settings Aspect ratios examples Memory Source: 4:3 Network menu Source: 16:9 PIP menu Source: 16:10 (native) Information menu...
- Page 9 E-Vision Laser13000 WU Series High Brightness Digital Video Projector INSTALLATION & QUICK START GUIDE Rev A June 2019 119-946A...
-
Page 10: What's In The Box
Digital Projection Ltd. E-Vision Laser 13000 WU Series What's in the box? What's in the box? Notes Make sure your box contains everything listed. If any pieces are missing, contact your dealer. Only one remote is supplied with the projector. -
Page 11: Connecting The Power Supply
Connecting the power supply Digital Projection Ltd. E-Vision Laser 13000 WU Series Connecting the power supply Notes 1. Adjust the VOLTAGE SELECT switch to the required voltage Use only the power cable provided. 2. Firmly push the mains connector into the socket... -
Page 12: Projector Overview
Digital Projection Ltd. E-Vision Laser 13000 WU Series Projector overview Projector overview Notes 1. Air inlet 2. Front infrared window 3. Lens mount 4. Air inlet 5. Rear infrared window 6. Air outlet 7. Connections panel 8. Control panel 9. Adjustable feet 10. -
Page 13: Control Panel
Control panel Digital Projection Ltd. E-Vision Laser 13000 WU Series Control panel Notes 1. POWER Switches the projector on and off (STANDBY). 2. INPUT Switches to the next input source. 3. AUTO SYNC AUTO CENTER Re-synchronises with the current input signal. -
Page 14: Projector Indicators
Digital Projection Ltd. E-Vision Laser 13000 WU Series Control panel Projector indicators Notes TEMP. Off = no problem Flashing red = temperature error LIGHT Off = light is switched off Flashing green = light is preparing to switch on Flashing red (cycles of six flashes) = light module failure... -
Page 15: Remote Control
Remote control Digital Projection Ltd. E-Vision Laser 13000 WU Series Remote control Notes 1. Power ON / OFF Turns power on and off. 2. Pic Mute OPEN / CLOSE Shows and hides the projected image. When OFF, the light source is completely switched off and the screen is black. - Page 16 Digital Projection Ltd. E-Vision Laser 13000 WU Series Remote control 11. LENS adjustment Notes FOCUS IN / OUT: adjust focus. SHIFT: press and hold this button, then use the Navigation arrow buttons to move the lens. ZOOM IN / OUT: adjust zoom.
- Page 17 Remote control Digital Projection Ltd. E-Vision Laser 13000 WU Series 17. DISPLAYPORT 1 / R / numeric input 4 Notes Select DisplayPort 1 input. 18. HD-T / G / numeric input 5 Select the HDBaseT input. 19. VGA / 3D / numeric input 7...
-
Page 18: Infrared Reception
Digital Projection Ltd. E-Vision Laser 13000 WU Series Remote control Infrared reception Notes The projector has infrared sensors at the front and back. 40˚ The angle of acceptance is 40°. Make sure that the remote control is within the angle of acceptance when trying to control the projector. -
Page 19: Positioning The Screen And Projector
Positioning the screen and projector Digital Projection Ltd. E-Vision Laser 13000 WU Series Positioning the screen and projector Notes 1. Install the screen, ensuring that it is in the best position for viewing by your audience. Always allow the 2. Mount the projector, ensuring that it is at a suitable distance from the screen for the image to projector to cool for 5 fill the screen. -
Page 20: Roll And Pitch
Digital Projection Ltd. E-Vision Laser 13000 WU Series Positioning the screen and projector Roll and pitch Notes The projector can be operated in numerous positions. In portrait mode, it is 360˚ recommended to position the 30˚ projector with inputs facing upward, as shown in the diagram. -
Page 21: Changing The Lens
Changing the lens Digital Projection Ltd. E-Vision Laser 13000 WU Series Changing the lens Notes Inserting a new lens Before changing the lens, always make sure 1. Remove the lens aperture cap from the projector. the projector is switched off and fully disconnected from its power supply. -
Page 22: Removing The Lens
Digital Projection Ltd. E-Vision Laser 13000 WU Series Changing the lens Removing the lens Notes 1. Push the lens release button all the way in 2. Turn the lens anti-clockwise until it disengages 3. Slowly remove the lens. Installation & Quick Start Guide... -
Page 23: Operating The Projector
Operating the projector Digital Projection Ltd. E-Vision Laser 13000 WU Series Operating the projector Notes Switching the projector on See Connecting the power supply on page 11. 1. Ensure a lens is fitted. Connect the power cable between the mains supply and the projector. (See Connecting the power supply above.) Switch on at the switch next to the power connector. -
Page 24: Adjusting The Lens
Digital Projection Ltd. E-Vision Laser 13000 WU Series Operating the projector Adjusting the lens Notes The lens can be adjusted using the Lens menu, or using the lens buttons on the remote control. Lens menu The Lens menu provides access to the Lens Control setting and the Lens Center command. - Page 25 E-Vision Laser13000 WU Series High Brightness Digital Video Projector CONNECTION GUIDE Rev A June 2019 119-946A...
-
Page 26: Signal Inputs
Digital Projection Ltd. E-Vision Laser 13000 WU Series Signal inputs Signal inputs Notes Digital inputs and outputs 1. HDBaseT For simultaneous Receives digital signal from HDBaseT-compliant RS-232 B/Pb R/Pr MONITOR OUT TRIGGER HDBaseT and LAN devices. Connect an HDBaseT cable. -
Page 27: Edid On The Displayport, Hdmi, And Hdbaset Inputs
Signal inputs Digital Projection Ltd. E-Vision Laser 13000 WU Series EDID on the DisplayPort, HDMI, and HDbaseT inputs Notes If you are using a computer graphics card or another source that obeys the EDID protocol, the source will automatically configure itself to suit the capability of the projector. -
Page 28: 3D Connections
Digital Projection Ltd. E-Vision Laser 13000 WU Series 3D connections 3D connections Notes 1. HDBaseT Receives 3D signal from HDBaseT-compliant devices. RS-232 R/Pr MONITOR OUT B/Pb TRIGGER Connect an HDBaseT cable. 2. HDMI I / Dual Pipe Left HDMI 1.4b input supporting Frame Sequential and Dual Pipe 3D with HDCP 1.4. -
Page 29: 3D Sources Up To 60Hz Requiring Frame Doubling And Left/Right Interleaving
3D connections Digital Projection Ltd. E-Vision Laser 13000 WU Series 3D sources up to 60Hz requiring frame doubling and left/right interleaving Notes 1. Connect to one of the following inputs on the connection panel: HDMI I HDMI II HDBaseT 2. Set 3D Format in the 3D menu to match the format of the incoming signal. Choose from Auto, Side by Side (Half) and Top and Bottom. -
Page 30: 3D Sync
Digital Projection Ltd. E-Vision Laser 13000 WU Series 3D connections 3D Sync Notes 1. 3D Input 2. 3D Sync In 3. 3D Sync Out 4. IR emitter or Zscreen Connection Guide Rev A June 2019 page 30... -
Page 31: Control Connections
The remote control can be connected using a standard 3.5 mm mini jack cable (tip-ring-sleeve, or TRS). 4. HDBaseT/LAN The projector’s features can be controlled via a LAN connection, using Digital Projection’s Projector Controller application or a terminal-emulation program. Connection Guide... -
Page 32: Lan Connection Examples
Control connections LAN connection examples Notes The projector’s features can be controlled via a LAN connection, using Digital Projection’s Projector Controller application or a terminal emulation program. With a LAN connection the projector can serve a web page offering basic projector controls. -
Page 33: Rs232 Connection Example
Control connections Digital Projection Ltd. E-Vision Laser 13000 WU Series RS232 connection example Notes All of the projector’s features can be controlled via a serial connection, using commands described in the Protocol Guide. The Protocol Guide is available separately Straight through cable... - Page 34 Digital Projection Ltd. E-Vision Laser 13000 WU Series This page is intentionally left blank Rev A June 2019...
- Page 35 E-Vision Laser13000 WU Series High Brightness Digital Video Projector OPERATING GUIDE Rev A June 2019 119-946A...
-
Page 36: Using The Menus
Digital Projection Ltd. E-Vision Laser 13000 WU Series Using the menus Using the menus Notes Opening the Menu Access the various menus using AUTO CENTER POWER INPUT ASPECT PIC MUTE either the projector control panel or SYNC LENS the remote control. On either device: 1. -
Page 37: Exiting Menus And Closing The Osd
Using the menus Digital Projection Ltd. E-Vision Laser 13000 WU Series Exiting menus and closing the OSD Notes To go back to the previous page: Main Menu Main Menu 1. Press EXIT. Input HDMI 1 ▲ To close the OSD: Test Pattern ►... -
Page 38: Accessing Sub Menus
Digital Projection Ltd. E-Vision Laser 13000 WU Series Using the menus Accessing sub menus Notes Use the UP and DOWN arrow buttons to highlight the sub-menu, then press ENTER/OK. Executing commands If the item contains a command, highlighting it reveals an OK... -
Page 39: Editing Projector Settings
Using the menus Digital Projection Ltd. E-Vision Laser 13000 WU Series Editing projector settings Notes If the highlighted menu item contains a list of values to choose from, you can change the value by doing the Menu Name Some menu items may be... -
Page 40: Editing Numeric Values
Digital Projection Ltd. E-Vision Laser 13000 WU Series Using the menus Editing numeric values Notes Some parameters take numeric values without using sliders - for example, color matching values or IP Data addresses. x: 0.658 y: 0.339 1. Use the UP and DOWN arrow buttons to highlight the row containing the numeric field you wish to edit. -
Page 41: Using The Projector
Using the projector Digital Projection Ltd. E-Vision Laser 13000 WU Series Using the projector Notes Main menu Input Main Menu Main Menu See Signal inputs on Press ENTER/OK to open the list of available inputs. page 26 for information Use the UP and DOWN arrow buttons to select an... -
Page 42: Lens Menu
Digital Projection Ltd. E-Vision Laser 13000 WU Series Using the projector Lens menu Notes Lens Lock Lens When this feature is On, all other Lens menu items are disabled. Lens Lock Lens Control Opens a sub-menu, see below. Lens Control ►... -
Page 43: Lens Memory
Using the projector Digital Projection Ltd. E-Vision Laser 13000 WU Series Lens memory Notes This menu allows you to load, save and delete up to ten lens presets, containing position, zoom, focus and shift Lens Memory adjustment information. Load Memory ►... -
Page 44: Image Menu
Digital Projection Ltd. E-Vision Laser 13000 WU Series Using the projector Image menu Notes Picture Mode Image Choose from High Bright, Presentation and Video. Use a different setting depending the type of input source. Picture Mode High Bright Press ENTER/SELECT to open the list. -
Page 45: Position And Phase
Using the projector Digital Projection Ltd. E-Vision Laser 13000 WU Series Position and phase Notes V Position and H Position Position and Phase Some of the settings Set the sliders as required. within the Position and V Position Phase Phase sub-menu, Phase, Adjusts the phase of the pixel sampling clock relative to the incoming signal. -
Page 46: Noise Reduction
Digital Projection Ltd. E-Vision Laser 13000 WU Series Using the projector Noise reduction Notes Temporal Noise Reduction A time-based filter that removes the noise on the luminance component. Temporal Block This filter helps reduce block noise, which appears like small blocks in the image and is caused by Block MPEG compression. -
Page 47: Color Menu
Using the projector Digital Projection Ltd. E-Vision Laser 13000 WU Series Color menu Notes Color Color Space Auto Color Mode ColorMax ColorMax Peak Manual Color Matching ► Color Temperature Native Gains and Lifts ► Color space In most cases, the Auto setting determines the correct colorspace to use. If it does not, you can choose a specific... -
Page 48: Color Mode
Digital Projection Ltd. E-Vision Laser 13000 WU Series Using the projector Color mode Notes The projector can work in the following color modes: ColorMax, Manual Color Matching, Color Temperature Color Only one color mode can and Gains and Lifts. be selected at a time. -
Page 49: Manual Color Matching
Using the projector Digital Projection Ltd. E-Vision Laser 13000 WU Series Manual color matching Notes 1. Set Color Mode to Manual Color Matching. Manual Color Matching 2. Open the Manual Color Matching submenu. Auto Test Pattern Here you can do the following: ►... -
Page 50: Color Matching Parameters Explained
Digital Projection Ltd. E-Vision Laser 13000 WU Series Using the projector Color matching parameters explained Notes The levels of hue, saturation and gain in the Manual Color Matching menu change the color values in the following ways: 1. Hue Specifies the position of each color (red, yellow, green, cyan, blue and magenta) relative to its neighboring colors. -
Page 51: Color Temperature
Using the projector Digital Projection Ltd. E-Vision Laser 13000 WU Series Color temperature Notes 1. Set Color Mode to Color Temperature. Color 2. Navigate to the Color Temperature setting. Choose a value from 3200K (warmer) to 9300K (cooler) or Color Space Auto Native (no correction). -
Page 52: Geometry Menu
Digital Projection Ltd. E-Vision Laser 13000 WU Series Using the projector Geometry menu Notes This menu allows you to compensate for image distortions caused by an unusual projection angle or irregular Geometry Select a Warping Mode to screen surface. activate it. Access its... -
Page 53: Theaterscope Setting
Using the projector Digital Projection Ltd. E-Vision Laser 13000 WU Series Theaterscope setting Notes The TheaterScope setting is used in combination with an anamorphic lens to restore 2.35: images packed into a 16:9 frame. Such images are projected with black TheaterScope is used with lines at the top and bottom of the 16:9 screen to make up for the difference in aspect ratios. -
Page 54: Digital Zoom
Digital Projection Ltd. E-Vision Laser 13000 WU Series Using the projector Digital zoom Notes Digital zooming enlarges a section of the image, while the area outside the enlarged section is cropped out to Digital Zoom Digital Zoom is a preserve the overall image size. -
Page 55: Overscan
Using the projector Digital Projection Ltd. E-Vision Laser 13000 WU Series Overscan Notes Use this setting to compensate for noisy or badly defined image edges. Geometry Crop removes unwanted artifacts from the edges of your image by cropping the edges. -
Page 56: Blanking
Digital Projection Ltd. E-Vision Laser 13000 WU Series Using the projector Blanking Notes Use this feature to: Blanking fit an odd-sized screen; cut off timecode dots in the top line of a picture; Bottom cut off subtitles, etc. Left Select the edge you wish to blank and use the LEFT and RIGHT arrow buttons to determine the amount of Right correction. -
Page 57: Keystone
Using the projector Digital Projection Ltd. E-Vision Laser 13000 WU Series Keystone Notes Use this setting to compensate for any distortion caused by the projector being in a different horizontal or vertical Keystone Max rotation in Keystone plane to the screen. -
Page 58: Keystone Example
Digital Projection Ltd. E-Vision Laser 13000 WU Series Using the projector Keystone example Notes The projector is positioned at an angle The resulting image is distorted The image is corrected when Keystone is applied Operating Guide Rev A June 2019... -
Page 59: Keystone Settings
Using the projector Digital Projection Ltd. E-Vision Laser 13000 WU Series Keystone settings Notes 1. Projector to the left The projector is positioned to the left of the screen. To correct, apply a positive Horizontal Keystone value using the RIGHT arrow button. -
Page 60: Corners
Digital Projection Ltd. E-Vision Laser 13000 WU Series Using the projector 4 corners Notes For each corner, apply horizontal and / or vertical correction as necessary to restore the rectangular shape of the 4 Corners Corner corrections image. provide a simple setup for Top Left Corner ►... -
Page 61: Top Right Corner Example
Using the projector Digital Projection Ltd. E-Vision Laser 13000 WU Series Top right corner example Notes In this illustration, the top right corner requires both horizontal and vertical correction. Top Right Corner Adjustment Top Right Corner x Top Right Corner y... -
Page 62: Rotation
Digital Projection Ltd. E-Vision Laser 13000 WU Series Using the projector Rotation Notes Use this feature for example to correct a mounting error causing the image not to be level with the screen. Rotation Rotation Reset Operating Guide Rev A June 2019... -
Page 63: Rotation Example
Using the projector Digital Projection Ltd. E-Vision Laser 13000 WU Series Rotation example Notes 1. DMD™ area The DMD™ is not rotated. It still covers the area that would be occupied by the image without correction. 2. Rotated image The image is smaller than the surrounding DMD™ area. It is scaled in order to remain within the DMD™... -
Page 64: Pincushion / Barrel
Digital Projection Ltd. E-Vision Laser 13000 WU Series Using the projector Pincushion / barrel Notes Pincushion or barrel distortions are the result of poor or incorrect tensioning of the screen or using a surface that Pincushion / Barrel is not flat. -
Page 65: Arc
Using the projector Digital Projection Ltd. E-Vision Laser 13000 WU Series Notes This feature is similar to Pincushion / Barrel but allows you to apply curvature to each edge of the image Please note that a positive independently so you can have any combination of corrections. -
Page 66: Custom Warp
Digital Projection Ltd. E-Vision Laser 13000 WU Series Using the projector Custom warp Notes This feature permits selection of predefined User warp maps. Use the Projector Controller PC application to Custom Warp create the custom warp maps. Custom warp maps provide non-linear curvature correction for curved or spherical screens and other irregular User 1 shaped surfaces such as building mapping. -
Page 67: Edge Blend Menu
Using the projector Digital Projection Ltd. E-Vision Laser 13000 WU Series Edge blend menu Notes Use this menu to blend together images from an array of two or more projectors. The feature feathers the light Edge Blend When Edge Blend is set to... -
Page 68: Blend Start
Digital Projection Ltd. E-Vision Laser 13000 WU Series Using the projector Blend start Notes Use the blend start options to deactivate pixels at the edge of the image and set the start point for the blended Blend Start region. Use the LEFT and RIGHT arrow buttons to set the start point of the blended regions: 1. -
Page 69: Blend Width
Using the projector Digital Projection Ltd. E-Vision Laser 13000 WU Series Blend width Notes Use the LEFT and RIGHT arrow buttons to set the width of the blended regions: Blend Width 1. Top 2. Bottom Bottom 3. Left Left 4. Right... -
Page 70: Black Level Uplift
Digital Projection Ltd. E-Vision Laser 13000 WU Series Using the projector Black level uplift Notes Black in the blended regions appears less dark than in the rest of the image. To compensate for this, use this Black Level Uplift Enable Align Pattern from... -
Page 71: 3D Menu
Using the projector Digital Projection Ltd. E-Vision Laser 13000 WU Series 3D menu Notes Use this menu to enable, disable and set up 3D input, as follows: If 3D Format is set to Off, 3D Format — Off, Dual Pipe and Frame Sequential. -
Page 72: 3D Types
Digital Projection Ltd. E-Vision Laser 13000 WU Series Using the projector 3D types Notes To display a 3D image if is first necessary to select the 3D format. This can either be Frame Sequential or Dual Pipe. These formats are described below: Dual Pipe (LEFT and RIGHT) The left and right eye images are delivered on two separate HDMI links, which the projector will interleave for 3D display. -
Page 73: Some 3D Settings Explained
Using the projector Digital Projection Ltd. E-Vision Laser 13000 WU Series Some 3D settings explained Notes Dark time In order to achieve maximum light output and Banding can be caused if the image is displayed before each a smooth grayscale, whilst Fully On eye of the 3D switching glasses or ZScreen is not fully open. -
Page 74: Sync Offset
Digital Projection Ltd. E-Vision Laser 13000 WU Series Using the projector Sync offset Notes The sync signal from the 3D server will be in phase with the Incoming video frames generated by its graphics card. However, to compensate for switching delays in the glasses or ZScreen,... -
Page 75: Laser Menu
Using the projector Digital Projection Ltd. E-Vision Laser 13000 WU Series Laser menu Notes Power Mode Laser Eco will automatically set the laser power to 80%. Power Mode Normal Normal will set the power to 100%. Power Level – – – –... -
Page 76: Setup Menu
Startup Logo Choose from Off, Original and User. Select original to display the Digital Projection Ltd. logo on startup. Select User to display a custom logo. Use the projector controller application to set the custom logo for the User option. - Page 77 Using the projector Digital Projection Ltd. E-Vision Laser 13000 WU Series Trigger1 and Trigger 2 Setup Notes Choose from Screen, 5:4, 4:3, 16:10, 16:9, 1.88, 2.35, TheaterScope, Source, Unscaled or RS232 to ▲ determine what will cause each trigger output to activate.
-
Page 78: Colormax
Digital Projection Ltd. E-Vision Laser 13000 WU Series Using the projector ColorMax Notes ColorMax permits seven point color matching of red, green, blue, yellow, cyan, magenta and white. ColorMax The Projector Controller software is available for You can enter your own gamut values here, or edit values you have imported using the Projector Controller Measured Data ►... -
Page 79: Power On/Off
Using the projector Digital Projection Ltd. E-Vision Laser 13000 WU Series Power on / off Notes Auto Power Off Power on/off Set this to On if you want the projector to go into STANDBY mode when no input source is detected for 20 minutes. -
Page 80: Clock Adjust
Digital Projection Ltd. E-Vision Laser 13000 WU Series Using the projector Clock adjust Notes Use this menu to set date (in dd:MM:yyyy format), time (in HH:mm format) and time zone. Clock Adjust The date and time set here will affect any schedule created within the Power On/Off menu. -
Page 81: Memory
Using the projector Digital Projection Ltd. E-Vision Laser 13000 WU Series Memory Notes The current image settings can be saved as a preset, which you can recall later. The default settings can be Memory Presets from one input recalled at any time as well. -
Page 82: Network Menu
Digital Projection Ltd. E-Vision Laser 13000 WU Series Using the projector Network menu Notes Network Mode Network Choose between Projector Control and Service. Network Mode Projector Control DHCP, IP, Subnet Mask, Gateway, DNS Set DHCP to On if the IP address is to be assigned by a DHCP server, or Off if it is to be set here. -
Page 83: Pip Menu
Using the projector Digital Projection Ltd. E-Vision Laser 13000 WU Series PIP menu Notes PIP Turn PIP on and off. Source Select an input source for the PIP image. Any combinations are possible between main and PIP input source, as long as one of the inputs is either DisplayPort or 3G-SDI. -
Page 84: Information Menu
Digital Projection Ltd. E-Vision Laser 13000 WU Series Using the projector Information menu Notes This menu gives information about software and hardware configuration, input source and laser operating times Information It also allows you to restore the factory default settings. -
Page 85: System Status
Using the projector Digital Projection Ltd. E-Vision Laser 13000 WU Series System status Notes System Status Atmospheric Pressure 98988 Pa (116m) AC Voltage 160V - 264V Ceiling Mode Tilt Angle 4 deg Portrait Angle 0 deg Altitude Mode Auto Laser Power... -
Page 86: Factory Reset
Digital Projection Ltd. E-Vision Laser 13000 WU Series Using the projector Factory reset Notes To restore the factory default settings: Information Factory reset does not reset the Network settings, 1. Navigate to Factory Reset and press ENTER/OK. Model Name E-VisionLaser 13000 WU or High Altitude mode 2. -
Page 87: Served Web Pages
Served web pages Digital Projection Ltd. E-Vision Laser 13000 WU Series Served web pages Notes The served web pages allow you to control the projector remotely via LAN. The default IP address is 192.168.0.100. Operating Guide Rev A June 2019... - Page 88 Digital Projection Ltd. E-Vision Laser 13000 WU Series Served web pages Notes Operating Guide Rev A June 2019 page 88...
- Page 89 Served web pages Digital Projection Ltd. E-Vision Laser 13000 WU Series Notes Operating Guide Rev A June 2019 page 89...
- Page 90 Digital Projection Ltd. E-Vision Laser 13000 WU Series Served web pages Notes Operating Guide Rev A June 2019 page 90...
- Page 91 Served web pages Digital Projection Ltd. E-Vision Laser 13000 WU Series Notes Operating Guide Rev A June 2019 page 91...
- Page 92 Digital Projection Ltd. E-Vision Laser 13000 WU Series This page is intentionally left blank Rev A June 2019...
- Page 93 E-Vision Laser13000 WU Series High Brightness Digital Video Projector REFERENCE GUIDE Rev A June 2019 119-946A...
-
Page 94: Choosing A Lens
Digital Projection Ltd. E-Vision Laser 13000 WU Series Choosing a lens Choosing a lens Notes A number of lenses are available. Which lens you choose depends on the screen size, image aspect ratio, throw distance and light output. Throw distance... -
Page 95: Basic Calculation
Choosing a lens Digital Projection Ltd. E-Vision Laser 13000 WU Series Basic calculation Notes Identify the required lens by calculating the throw ratio. The basic calculation on this page does not take A throw ratio is the ratio of the throw distance to the screen width into consideration DMD™... -
Page 96: Basic Calculation Example
Digital Projection Ltd. E-Vision Laser 13000 WU Series Choosing a lens Basic calculation example Notes 1. Calculate the throw ratio using the formula. The basic calculation on Your screen is 4.5m wide and you wish to place the projector approximately 11m from the... -
Page 97: Full Lens Calculation
Choosing a lens Digital Projection Ltd. E-Vision Laser 13000 WU Series Full lens calculation Notes Introducing TRC The choice of lens will affect the image size and will address discrepancies between the DMD™ TRC can only be applied if resolution and the source. -
Page 98: Calculating Trc
Digital Projection Ltd. E-Vision Laser 13000 WU Series Choosing a lens Calculating TRC Notes To calculate TRC, use the following formula: TRC can only be applied if greater than 1. If TRC is 1 or less, disregard it and calculate the throw ratio TRC table using the basic formula. -
Page 99: Full Lens Calculation Example
Choosing a lens Digital Projection Ltd. E-Vision Laser 13000 WU Series Full lens calculation example Notes Your screen is 4.5m wide; you wish to place the projector approximately 11m from the screen. The source is 4:3. INFORMATION YOU NEED FOR THESE CALCULATIONS 1. -
Page 100: Screen Requirements
Digital Projection Ltd. E-Vision Laser 13000 WU Series Screen requirements Screen requirements Notes Fitting the image to the display If the source image supplied to the projector is smaller than the WUXGA resolution, the image will not fill the display. The following examples show how a number of common formats may be displayed, depending on your DMD™... -
Page 101: Wuxga Images Displayed Full Height
Screen requirements Digital Projection Ltd. E-Vision Laser 13000 WU Series WUXGA images displayed full height Notes 4:3 = 1.33:1 = 1596 pixels WUXGA = 16:10 = 1.6:1 = 1920 pixels Diagonal screen sizes Screen sizes are sometimes specified by their diagonal size (D). When dealing with large screens... -
Page 102: Positioning The Image
Digital Projection Ltd. E-Vision Laser 13000 WU Series Positioning the image Positioning the image Notes The normal position for the projector is at the centre of the See Lens control on screen. However, you can set the projector above or below the page 42 for more... - Page 103 Positioning the image Digital Projection Ltd. E-Vision Laser 13000 WU Series Any single adjustment outside the Notes ranges specified on the following page may result in an unacceptable See Lens control on level of distortion, particularly at the page 42 for more...
-
Page 104: Aspect Ratios Explained
Digital Projection Ltd. E-Vision Laser 13000 WU Series Aspect ratios explained Aspect ratios explained Notes The appearance of a projected image on the screen depends on a combination of the following: The display resolution is WUXGA with a 1920 x 1200 resolution, corresponding to an aspect ratio of 16:10... -
Page 105: Source: 16:9
Aspect ratios explained Digital Projection Ltd. E-Vision Laser 13000 WU Series Source: 16:9 Notes Aspect Ratio 16:10 Aspect Ratio: Source / 16:9 Source: 16:10 (native) Aspect Ratio: Source / 16:10 Reference Guide Rev A June 2019 page 105... -
Page 106: Aspect Ratio Example: Theatrescope
Digital Projection Ltd. E-Vision Laser 13000 WU Series Aspect ratios explained Aspect ratio example: TheatreScope Notes The TheaterScope setting is used in combination with an anamorphic lens to restore 2.35:1 images packed into a 16:9 frame. Such images are projected with black lines at the top and bottom of the 16:9 screen to make up for the difference in aspect ratios. -
Page 107: Appendix A: Supported Signal Input Modes
Appendix A: supported signal input modes Digital Projection Ltd. E-Vision Laser 13000 WU Series Appendix A: supported signal input modes Notes 2D formats HDMI / HD-BaseT Signal Frame Rate DisplayPort / Output Frame Rate Resolution Remarks YUV 8- YUV 10-... - Page 108 Digital Projection Ltd. E-Vision Laser 13000 WU Series Appendix A: supported signal input modes HDMI / HD-BaseT Signal Frame Rate DisplayPort / Output Frame Rate Notes Resolution Remarks YUV 8- YUV 10- YUV 12- Format (Hz) DVI-D (Hz) ü 480i 59.94...
-
Page 109: Formats
Appendix A: supported signal input modes Digital Projection Ltd. E-Vision Laser 13000 WU Series 3D formats Notes HB Dual-pipe V-Freq H Freq. HDMI DisplayPort / Output Frame *1: HB(High Bandwidth) Standard Resolution Remarks HDMI DisplayPort (Hz) Total (kHz) DVI-D Rate (Hz) - Page 110 Digital Projection Ltd. E-Vision Laser 13000 WU Series Appendix A: supported signal input modes HB Dual-pipe V-Freq H Freq. HDMI DisplayPort / Output Frame Notes Standard Resolution HDMI DisplayPort Remarks (Hz) Total (kHz) DVI-D Rate (Hz) (*1) (*1) Frame ü...
-
Page 111: Sdi Formats
Appendix A: supported signal input modes Digital Projection Ltd. E-Vision Laser 13000 WU Series SDI formats Notes Timing SDI Link Mode Signal Standards Color Encode Sampling Structure Bit Depth NTSC SMPTE 259M-C 270Mbps SD YCbCr 4:2:2 SMPTE 259M-C 270Mbps SD... -
Page 112: Appendix B: Wiring Details
Digital Projection Ltd. E-Vision Laser 13000 WU Series Appendix B: wiring details Appendix B: wiring details Notes Signal inputs and outputs HDMI 1 and 2 19 way type A connector 1. TMDS Data 2+ 2. TMDS Data 2 Shield HDMI: pin view of panel connector 3. -
Page 113: Displayport
Appendix B: wiring details Digital Projection Ltd. E-Vision Laser 13000 WU Series DisplayPort Notes DisplayPort 1.2 Pin 1 ML_Lane 0 (p) Lane 0 (positive) Pin 2 Ground Pin 3 ML_Lane 0 (n) Lane 0 (negative) Pin 4 ML_Lane 1 (p) -
Page 114: 3G-Sdi In, 3G-Sdi Out
Digital Projection Ltd. E-Vision Laser 13000 WU Series Appendix B: wiring details 3G-SDI in, 3G-SDI out Notes 75 ohm BNC 3G-SDI connector HDBaseT input RJ45 socket. HDBaseT / LAN Reference Guide Rev A June 2019 page 114... -
Page 115: Control Connections
Appendix B: wiring details Digital Projection Ltd. E-Vision Laser 13000 WU Series Control connections Notes Only one remote RJ45 socket (Shared with HDBaseT) connection (RS232 or LAN) should be used at any one time. HDBaseT / LAN RS232 9 way D-type connector 1. -
Page 116: Appendix C: Glossary Of Terms
Digital Projection Ltd. E-Vision Laser 13000 WU Series Appendix C: glossary of terms Appendix C: glossary of terms Notes 1080p An HDTV resolution which corresponds to 1920 x 1080 pixels (a widescreen aspect ratio of 16:9). 3D active glasses Wireless battery-powered glasses with LCD shutters. Synchronization information is communicated to the glasses by means of an infrared (IR) or radio frequency (RF) emitter which is connected to the Sync Out terminal on the projector. - Page 117 Appendix C: glossary of terms Digital Projection Ltd. E-Vision Laser 13000 WU Series Notes Blanking (projection) The ability to intentionally turn off, that is, set to black, areas around the edges of the projected image. It is sometimes referred to as “curtains” since it can be used to blank an area of image that literally falls on the curtains at the side of the screen in a movie theater.
- Page 118 Digital Projection Ltd. E-Vision Laser 13000 WU Series Appendix C: glossary of terms Contrast (electronic control) Notes The adjustment of the white point of the image without affecting the black point. This increases the intensity range of the displayed image.
- Page 119 Appendix C: glossary of terms Digital Projection Ltd. E-Vision Laser 13000 WU Series Edge tear Notes An artifact observed in interlaced video where the screen appears to be split horizontally. Edge tears appear when the video feed is out of sync with the refresh rate of the display device.
- Page 120 Digital Projection Ltd. E-Vision Laser 13000 WU Series Appendix C: glossary of terms Notes HDCP (High-bandwidth Digital Content Protection) An encryption scheme used to protect video content. HDTV (High Definition Television) A television system with a higher resolution than SDTV and EDTV. It can be transmitted in various formats, notably 1080p and 720p.
- Page 121 Appendix C: glossary of terms Digital Projection Ltd. E-Vision Laser 13000 WU Series Luminance Notes Also known as ‘Y’, this is the part of a Component Video signal which affects the brightness, i.e. the black and white part. Noise Electrical interference displayed on the screen.
- Page 122 Digital Projection Ltd. E-Vision Laser 13000 WU Series Appendix C: glossary of terms Primary colors Notes Three colors any two of which cannot be mixed to produce the third. In additive color television systems the primary colors are red, green and blue.
- Page 123 Appendix C: glossary of terms Digital Projection Ltd. E-Vision Laser 13000 WU Series Notes Test pattern A still image specially prepared for testing a projection system. It may contain various combinations of colors, lines and geometric shapes. TheaterScope An aspect ratio used in conjunction with a special anamorphic lens to display 2.35:1 images packed into a 16:9 frame.
- Page 124 Digital Projection Ltd. E-Vision Laser 13000 WU Series Appendix C: glossary of terms Notes This is the luminance input (brightness) from a Component Video signal. Color difference signals used with ‘Y’ for analog Component Video inputs. They provide information about the signal color. Not to be confused with Cr, ZScreen A special kind of light modulator which polarizes the projected image for 3D viewing.
- Page 125 Contact Information: Digital Projection Japan Digital Projection Asia Digital Projection China Digital Projection Inc. Digital Projection Limited 〒 105-0012 東 京 都 港 区 芝 大 門 16 New Industrial Road, #02-10 中 国 北 京 市 朝 阳 区 芍 药 居 北...
