Digital Projection E-Vision 8000 Series User Manual page 44

Digital Projection
E-Vision 8000 series
continued
ALIGNMENT Menu
Blanking sub menu
•
Press to open the Blanking sub menu.
ENTER
Top, Bottom, Left and Right
•
Set each slider as required.
Reset
•
Press ENTER to reset all blanking settings to zero.
Rev A April 2012
A TOUR OF THE MENUS Operating Guide
Notes
See also Using the Menus, earlier
in this guide and Menu Map, later in
this guide.
Only one of the Warp controls, or
the Blanking control can be used
at any one time.
Exception: all four Corner controls
can be used at the same time.
If the Edge Blend feature is in
use, then only the four Corner
controls can be used.
If you are not sure which Warp
control is in use, then select ,
Reset
from the menu to reset all
Warp
controls to zero.
Page Op_16
