Digital Projection
E-Vision 8000 series
S-Video input
4 pin mini-DIN
1
Y Ground
2
C Ground
3
Luminance (Y)
4
Chrominance (C)
Video input
1 x RCA Phono
Composite Video
Rev A
April 2012
WIRING DETAILS
pin view of female connector
Connection Guide
Notes
For full details of all input settings,
menu in the
see the
INPUT
Operating Guide.
Page Conn_7
