Rastergraf
1.6 Monitor Requirements
Rastergraf graphics boards can be used with a variety of monitors. For
best performance a monitor should have the following features:
• VGA compatible 5 Wire RGB with separate TTL horizontal and
• Switchable Termination (for monitor loopthrough)
• Height, pincushion, width, phase, and position controls
• Autotracking horizontal and vertical synchronization
• See tables in Section 1.4 (above) for basic timing requirements
Notes
The Eclipse3 software defaults to standard Multiscan 5-wire RGBHV
(VGA compatible) settings. If you require Sync On Green, be sure to
install SYNC ON GREEN jumper.
Eclipse3 graphics boards DO NOT support interlaced operation.
vertical sync or 3 Wire RGB with sync on green (see note below)
General Information 1-23
