Ruggedization Levels:
Table 1-3 Rastergraf Ruggedization Levels Chart
Air-Cooled
Spec
Level 0
Argus
Gemini
Applicable
Sirena
Graphics
Eclipse3
Board(s)
Topaz
Garnet
Operating
Temperature 0°C to 50°C
(4, 6)
Storage -40°C to 85°C -40°C to 85°C -55°C to 125°C -55°C to 125°C -55°C to 125°C -55°C to 125°C
Humidity 0 to 95% non-
Operating condensing
Humidity 0 to 95%
Storage condensing
Vibration 2 g peak
Sine (1) 15-2 kHz
Vibration 0.01 g2/Hz
Random (2) 15-2 kHz
Shock (3) 20 g peak
Conformal
optional
Coat (5)
Order
/CA or /CS
Option (7)
Notes:
1. Sine vibration based on a sine sweep duration of 10 minutes per axis in each of three mutually
perpendicular axes. May be displacement limited from 15 to 44 Hz, depending on specific test
equipment. Shock and Vibration values not completely verified.
2. Random vibration 60 minutes per axis, in each of three mutually perpendicular axes.
3. Three hits in each axis, both directions, 1/2 sine and saw tooth. Total 36 hits.
4. Standard air-flow is 8 cfm at sea level. Some higher-powered products may require additional
airflow. Consult the factory for details.
5. Conformal coating type to be specified by customer. Consult the factory for details.
6. Temperature is measured at the card interior (not at edge).
7. Last letter in ordering option: A for Acrylic Conformal Coating, S for Silicone Conformal Coating
The following table shows the standard ruggedization
levels. At the time of writing, complete shock and vibration
testing has not been performed, but some boards have been
tested enough to expect full acceptance is possible. Please
contact Rastergraf Sales if you need this information.
Air-Cooled Air-Cooled
Level 50 Level 100
Gemini Gemini
Sirena Sirena
Eclipse3 Eclipse3
Topaz Topaz
Garnet Garnet
-20°C to 65°C -40°C to 71°C
0 to 100% non- 0 to 100% non-
condensing condensing
0 to 100% 0 to 100%
condensing condensing
2 g peak 10 g peak
15-2 kHz 15-2 kHz
0.02 g2/Hz 0.04 g2/Hz
15-2 kHz 15-2 kHz
20 g peak 30 g peak
optional optional
/A5A or /A5S /A1A or /A1S
Conduction-
Air-Cooled
cooled
Level 200
Level 100
Eclipse3
Topaz Garnet
Garnet
-40°C to 85°C -40°C to 71°C
0 to 100% non- 0 to 100% non-
condensing condensing
0 to 100% 0 to 100%
condensing condensing
10 g peak 10 g peak
15-2 kHz 15-2 kHz
0.04 g2/Hz 0.1 g2/Hz
15-2 kHz 15-2 kHz
30 g peak 40 g peak
optional yes
/A2A or /A2S /C1A or /C1S
General Information 1-13
Conduction-
cooled
Level 200
Garnet
-40°C to 85°C
0 to 100% non-
condensing
0 to 100%
condensing
10 g peak
15-2 kHz
0.1 g2/Hz
15 Hz-2 kHz
40 g peak
yes
/C2A or /C2S
