Rastergraf Eclipse3 Series User Manual page 19

Rastergraf
Fuse Element:
2
Local I C Channel:
Power-management:
PCI Bus Access:
PCI bus Interrupts:
Bus Loading:
Module Size:
PCI Subsystem Vendor ID: 0x10F0 (CW Vendor Code)
PCI Subsystem Device ID: 0x0003 for 16 MB boards, 0x0007 for 32 MB boards
Power Requirements:
The +5V supplied to the front panel connectors is protected
by a Positive Temperature Coefficient (PTC) resistor. It
resets automatically when the overload is removed.
2
The Eclipse3 uses I C, a 2 wire serial bus, to control the
following on-board devices:
THC63DV164 DVI transmitter (optional)
LM75 thermal sensor (optional)
AT24C02 2 Kb serial EEPROM (optional)
DDC2B display monitor control
With the proper software, the Borealis can power-down
unused functions and the VESA standard DDC2B lines
control the monitor.
Programmable Bus Address Registers (BARs) in the
Borealis map control and drawing engine registers, and
display memory through its 33/66 MHz PCI interface.
The Borealis can interrupt the PCI bus on the INTA line.
One PCI 2.1 compatible load
PMC: IEEE 1386-2001,
149 mm x 74 mm, 32-bit, 33/66 MHz, J1/J2
CompactPCI: PICMG 2.0 Rev 3, IEEE 1101.10,
3U form factor w/ ESD strip,
32-bit, 33/66 MHz, J1 only, no hotswap.
3U and 6U front panel options.
Optional rear-panel module connecting to
CPCI J2 is standard 3U rear I/O format.
3U and 6U rear panel options.
PCI: short PCI, 32-bit, 33/66 MHz, 64-bit
connector set is used for improved power
and ground distribution
Standard versions REQUIRE that the PMC, CompactPCI,
or PCI bus connectors supply both +5V and +3.3V. A
location for a local 3.3V regulator is provided on the PMC
and PCI boards for systems which do not supply 3.3V to
the backplane.
+5V +/- 5%, 0.2 A max
+3.3V +/- 5%, 1.2 A max
PCI Bus pin PRSNT1# is set low, indicating 7.5W max.
General Information 1-11
