2.4 Monitor Requirements

Rastergraf boards can be used with a variety of monitors. For best
performance a monitor should have the following features:
•
•
•
•
•
•
•
Notes
The software defaults to standard Multiscan 5-wire RGBHV (VGA
compatible) settings. If you require Sync On Green, be sure to select
SYNC ON GREEN when setting the Video Parameters.
Some versions of the graphics boards can support interlaced operation
including STANAG A, B, and/or C. Please contact Rastergraf for more
information.
Composite Video Signal:
2-12 Specifications
VGA compatible 5 Wire RGB with separate TTL horizontal and
vertical sync or 3 Wire RGB with sync on green (see note below)
Switchable Termination (for monitor loopthrough)
Height, pincushion, width, phase, and position controls
Autotracking horizontal and vertical synchronization
High bandwidth:
Horizontal refresh rate: 70 kHz at 1280 x 1024
See Section 2.3 for complete display timing information
135 MHz at 1280 x 1024
180 MHz at 1600 x 1200
90 kHz at 1600 x 1200
1 Volt peak to peak consisting of:
660 mV Reference White +
54 mV Reference Black +
286 mV Sync Level
