Rastergraf
Rastergraf - graphics and PMC carriers for embedded systems
ArgusPMC
Dual Channel High Resolution
Graphics Controllers with
Video Digitizers, USB 2.0, and Audio
Solaris
Real-Time Operating Systems
Features
• Functions as a dual-channel multi-media controller
• Dual independent 128-bit graphics controllers provide
no-compromise drawing engine performance at up to
1920 x 1200 (VGA) or 1600 x 1200 (DVI)
• 16 MB display memory per channel
• Dual video digitizers
• USB-2.0 Host controller
• Stereo Audio controller (CODEC)
• VxWorks, Linux, LynxOS, Solaris and Windows 2K/XP
for PMC
Windows
Linux
Advertisement
Related Manuals for Rastergraf ArgusPMC
Summary of Contents for Rastergraf ArgusPMC
- Page 1 1920 x 1200 (VGA) or 1600 x 1200 (DVI) • 16 MB display memory per channel • Dual video digitizers • USB-2.0 Host controller • Stereo Audio controller (CODEC) • VxWorks, Linux, LynxOS, Solaris and Windows 2K/XP Rastergraf - graphics and PMC carriers for embedded systems...
- Page 2 • CompactPCI and PCI carriers for one or two PMCs. An asynchronous PCI bridge supports all PMC interfaces from Please contact Rastergraf for more information or consult our 32-bit, 33 MHz to 64-bit, 66 MHz, while enabling the Borealis web page at www.rastergraf.com..
- Page 3 This allows for efficient use of off- screen memory and the ability to dynamically accommodate a variety The Rastergraf ArgusPMC is a PMC (PCI Mezzanine Card) multifunc- of image formats. tion display controller. Referring to the block diagram, the Argus is...
- Page 4 77 Hz 60 Hz Video Input Capabilities The ArgusPMC has two NTSC/PAL Conexant Fusion 878A The front panel connector provides access to the S-Video video digitizers which operated independently of each other. input for each digitizer. With pin sharing, it can instead support...
