3.6.3 Request for Help in Determining Video Timing Values
Use the following table to request help when you have a non-standard
video timing requirement.
Table 3-4 Eclipse3 Video Timing Parameter Request Form
Submit to:
Company Information
Company Name_______________________________
Contact______________________________________
Phone Number_____________________
Fax Number________________________
email______________________________
Monitor Information
Monitor Brand____________________ Model Number__________________
Eclipse3 Information
Model Number____________________ Serial Number__________________
Horizontal Timing Information
Note: Horizontal timings may be given in pixel units (if given) or time units.
Horizontal Pixels per Line Displayed____________________
Pixel Time or Frequency (optional)____________________
Horizontal Total Line Time or Frequency____________________
Horizontal Front Porch____________________
Horizontal Sync Width____________________
Horizontal Back Porch____________________
Vertical Timing Information
Note: Vertical timings may be given in line units or time units.
Vertical Lines Displayed__________
Vertical Lines Total or Frequency (Field Rate)_________
Vertical Front Porch____________________
Vertical Sync Width____________________
Vertical Back Porch____________________
Sync Information
Sync Polarity (+ or -): Composite:_____
Additional Notes
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
Rastergraf Technical Support
Fax (541) 923-6475 or email: support@rastergraf.com
Horizontal:_____ Vertical:_____
Programming On-board Devices 3-17
