Rastergraf Eclipse3 Series User Manual page 17

Rastergraf
Scroll, Pan, and Zoom:
Digital Output (Optional):
Composite Video Signal:
Display Timing:
Table 1-1 Eclipse3 SDL Platform Display Timing Specifications
Active
Display
640 x 480
800 x 600
1024 x 768
1152 x 900
1280 x 1024
1600 x 1200
1920 x 1200
Scroll - single line (smooth scroll).
Pan - anywhere on 16 byte boundaries
Zoom: horizontal: 2, 4, 8, 16, vertical: 2, 3 ,...,15, 16
The Eclipse3 can supply a digital output using a THine
THC63DV164 DVI encoder. The Borealis Video Out Bus,
which supplies TTL level RGB and Sync, is sampled and
multiplexed and driven onto 4 differential pairs.
Because of the high frequency nature of the TMDS signals,
it is vital that matched length, shielded pair cable be used
for DVI connections.
The standard front panel analog VGA connector is replaced
by a DVI-I connector. This connector supplies both the
digital DVI (TMDS) signals and VGA. Rastergraf can
supply an adapter that allows a standard VGA cable to be
used when a DVI display is not desired or available.
A jumper can be installed to select Sync-On-Green
operation on boot-up. The signal has the following
approximate values:
1 Volt peak to peak consisting of:
The Borealis chip display timing is programmable. The
following tables provide the timing values provided by
Rastergraf software.
Analog/ Bits per
Format
DVI
Both VGA 8, 16, 32
Both SVGA 8, 16, 32
Both UVGA 8, 16, 32
Both Sun 8, 16, 32
Both SXGA 8, 16, 32
Both UXGA 8, 16, 32
Analog WUXGA 8, 16, 32
660 mV Reference White +
54 mV Reference Black +
286 mV Sync Level
Vertical Horizontal
Pixel Refresh
60 Hz 31.55 KHz
60 Hz 39.35 KHz
70 Hz 58.86 KHz
66 Hz 64.92 KHz
74 Hz 82.86 KHz
60 Hz
60 Hz
Pixel
Refresh Clock
27 MHz
42 MHz
80.52 MHz
99.72 MHz
141.5 MHz
75 KHz 162.0 MHz
75 KHz 194.4 MHz
General Information 1-9
