1.5.4 Connections to the PCI Bus
SIDE A
1 n/c
2 n/c
3 n/c
4 JTAGTDIOH
5 VCC (5V)
6 PINTAL
7 n/c
8 VCC (5V)
9 n/c
10 byp (Vio)
11 n/c
12 keyway
13 keyway
14 n/c
15 PPCIRSTL
16 byp (Vio)
17 PCIGNTL
18 GND
19 n/c
20 PAD30H
21 VDD (3.3V)
22 PAD28H
23 PAD26H
24 GND
25 PAD24H
26 PIDSELH
27 VDD (3.3V)
28 PAD22H
29 PAD20H
30 GND
31 PAD18H
32 PAD16H
Note: byp means the pin is connected to a bypass capacitor on the graphics board but is
otherwise not used
SIDE B
n/c 1
n/c 2
GND 3
JTAGTDIOH 4
VCC (5V) 5
VCC (5V) 6
n/c 7
n/c 8
PRSNT1L 9
n/c 10
PRSNT2L 11
keyway 12
keyway 13
n/c 14
GND 15
PPCICLK 16
GND 17
PCIGNTL 18
byp (Vio) 19
PAD31H 20
PAD29H 21
GND 22
PAD27H 23
PAD25H 24
VDD (3.3V) 25
PCBE3L 26
PAD23H 27
GND 28
PAD21H 29
PAD19H 30
VDD (3.3V) 31
PAD17H 32
SIDE A
33 VDD (3.3V)
34 PFRAMEL
35 GND
36 PTRDYL
37 GND
38 PSTOPL
39 VDD (3.3V)
40 n/c
41 n/c
42 GND
43 PPARH
44 PAD15H
45 VDD (3.3V)
46 PAD13H
47 PAD11H
48 GND
49 PAD09H
50 keyway
51 keyway
52 PCBE0L
53 VDD (3.3V)
54 PAD06H
55 PAD04H
56 GND
57 PAD02H
58 PAD00H
59 byp (Vio)
60 n/c
61 VCC (5V)
62 VCC (5V)
63 GND
64 n/c
General Information 1-19
SIDE B
PCBE2L 33
GND 34
PIRDYL 35
VDD (3.3V) 36
PDEVSELL 37
GND 38
n/c 39
n/c 40
VDD (3.3V) 41
n/c 42
VDD (3.3V) 43
PCBE1L 44
PAD14H 45
GND 46
PAD12H 47
PAD10H 48
n/c 49
keyway 50
keyway 51
PAD08H 52
PAD07H 53
VDD (3.3V) 54
PAD05H 55
PAD03H 56
GND 57
PAD01H 58
byp (Vio) 59
n/c 60
VCC (5V) 61
VCC (5V) 62
n/c 63
GND 64
