Rastergraf
Caution
The static electricity that your body builds up normally can seriously
damage the components on the graphics board.
3. Wear a grounded wrist strap and touch a metal part of the computer
chassis. Remove the card slot blocking plate from the chassis. Then,
remove the graphics board from its anti static bag, and immediately
slide it into the slot.
Figure 2-6 Installation of a PCI Module into an Emerson MTX
4. After making sure the board is seated correctly, install the screw into
the place where the blocking plate was and which (now) holds the
graphics board's front panel
5. Close the computer.
Now, go to Section 2.7
2-12 Installing Your Peritek Graphics Board
