1.5 Monitor Requirements

Rastergraf display boards can be used with a wide variety of monitors. For
best performance a monitor should have the following features:
• VGA compatible 5 Wire RGB with separate TTL horizontal and
vertical sync or 3 Wire RGB with sync on green (see note below)
• Switchable Termination (for monitor loopthrough)
• Height, pincushion, width, phase, and position controls
• Autotracking horizontal and vertical synchronization
• High bandwidth: 135 MHz at 1280 x 1024
• Horizontal refresh rate:
Note
A standard Multiscan monitor can be plugged directly into the VFX-M's
adapter cable using a VGA cable with 15 pin D-Sub ends. However, in
order to avoid a green background, select NO SYNC ON GREEN when
setting up the VFX-M's Video Parameters.

Table 1-1 VFX-M Standard Display Timing Specifications

Display
Format
640 x 480
1024 x 768
1024 x 1024
1280 x 1024
1280 x 1024
1600 x 1280
Composite Video Signal:
1-10 General Information
Artisan Scientific - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisan-scientific.com
180 MHz at 1600 x 1280
70 kHz at 1280 x 1024
90 kHz at 1600 x 1280
Vertical Horizontal
Refresh Refresh
60 Hz 31.5 kHz
60 Hz 60 kHz
70 Hz 64 kHz
60 Hz 64 kHz
67 Hz 72 kHz
60 Hz 79 kHz
1 Volt peak to peak consisting of:
660 mV Reference White +
54 mV Reference Black +
286 mV Sync Level
Pixel
Clock
27 MHz
80 MHz
85 MHz
110 MHz
125 MHz
170 MHz
