2.9.2.3 Setting the Console Resolution
The initial system default console resolution of the Eclipse3 is 8 bits per
pixel, 1152 x 864 @ 60Hz. The Eclipse3 is capable of supporting
additional console mode resolutions (all are 8 bpp) as shown in the
following table:
Index
Index
To change the startup console display mode, identify the desired graphics
resolution and refresh rate and enter the corresponding index value (e.g, 6
is the index value for 800 x 600 @ 60hz) in place of the word
shown in the below.
[at the ok prompt]
type
receive 0:
type
receive 1:
type
receive ok
type
receive ok
2-22 Installing Your Peritek Graphics Board
Table 2-2 FCode Supported Display Modes
Graphics
1024 x 768
0
1024 x 768
1
1152 x 864
2 *
1152 x 864
3
1280 x 1024
4
1280 x 1024
5
800 x 600
6
800 x 600
7
8 640 x 480
9 640 x 480
1152 x 900
a
b 1152 x 900
c 1600 x 1200
d 1920 x 1200
* - initial system default
nvedit
[if, instead, you receive 0: and some text, type <ctrl-k> to clear the line]
index constant eclipse3-console-mode <return>
[if, instead, you receive 1: and some text, just ignore it]
^C
nvstore
Refresh Rate PC Type
60 Hz
UVGA
75 Hz
UVGA
60 Hz
Sun
75 Hz
Sun
60 Hz
SXGA
75 Hz
SXGA
60 Hz
SVGA
75 Hz
SVGA
60 Hz VGA
75 Hz VGA
60 Hz
Sun (old)
75 Hz Sun (old)
60 Hz UXGA
60 Hz WUXGA
, as
index
