Rastergraf
Caution
The static electricity that your body builds up normally can seriously
damage the components on the graphics board.
4. Wear a grounded wrist strap. Touch a metal part of the computer
chassis, remove the graphics board from its anti static bag, and
immediately slide it into the slot.
5. After making sure the board is seated correctly, lever the card in with
the injector(s) and tighten the screwlock on each end of the faceplate.
Now, go to Section 2.7.

Figure 2-8 Installing a CompactPCI Board

Installing Your Peritek Graphics Board 2-15
