1.5.3 Connections to the PMC Bus
J11
1 n/c
3 GND
5 n/c
7 BUSMODE1L
9 n/c
11 GND
13 PCICLK
15 GND
17 PMCREQL
19 byp (Vio)
21 AD28H
23 AD25H
25 GND
27 AD22H
29 AD19H
31 byp (Vio)
33 FRAMEL
35 GND
37 DEVSELL
39 GND
41 n/c
43 PAR
45 byp (Vio)
47 AD12H
49 AD09H
51 GND
53 AD06H
55 AD04H
57 byp (Vio)
59 AD02H
61 AD00H
63 GND
Notes: byp means the pin is connected to a bypass capacitor on the graphics board but
is otherwise not used.
1-18 General Information
n/c 2
PINTAL 4
n/c 6
VCC (5V) 8
n/c 10
n/c 12
GND 14
PMCGNTL 16
VCC (5V) 18
AD31H 20
AD27H 22
GND 24
C/BE3L 26
AD21H 28
VCC (5V) 30
AD17H 32
GND 34
IRDYL 36
VCC (5V) 38
n/c 40
n/c 42
GND 44
AD15H 46
AD11H 48
VCC (5V) 50
C/BE0L 52
AD05 54
GND 56
AD03H 58
AD01H 60
VCC (5V) 62
n/c 64
J12
1 n/c
3 n/c
5 n/c
7 GND
9 n/c
11 BUSMODE2L
13 PCIRSTL BUSMODE3L
15 VDD (3.3V) BUSMODE4L 16
17 n/c
19 AD30H
21 GND
23 AD24H
25 IDSEL
27 VDD (3.3V)
29 AD18H
31 AD16H
33 GND
35 TRDYL
37 GND
39 n/c
41 VDD (3.3V)
43 C/BE1L
45 AD14
47 M66EN
49 AD08H
51 AD07H
53 VDD (3.3V)
55 n/c
57 n/c
59 GND
61 n/c
63 GND
n/c 2
n/c 4
GND 6
n/c 8
n/c 10
VDD (3.3V) 12
14
GND 18
AD29H 20
AD26H 22
VDD (3.3V) 24
AD23H 26
AD20H 28
GND 30
C/BE2L 32
n/c 34
VDD (3.3V) 36
STOPL 38
GND 40
n/c 42
GND 44
AD13H 46
AD10H 48
VDD (3.3V) 50
n/c 52
n/c 54
GND 56
n/c 58
n/c 60
VDD (3.3V) 62
n/c 64
