1.7 Configuration Information

The basic graphics board includes:
• Rastergraf Borealis Graphics Processor with 8, 16, or 32 bit/pixel
• 16 MB SGRAM
• hardware interrupts, pan, scroll, and zoom and cursors
• analog video outputs
• Quad Image BIOS supports VGA, FCode, DVI, and Sync on Green
(SOG)
An on-board 3.3V regulator can be provided on the PMC and PCI boards
for systems which do not supply 3.3V to the backplane. CPCI backplanes
always have 3.3V. Please contact Rastergraf for more information about
this and other special configurations.
Operating
System
Solaris 2.6 - 10
Solaris 2.6 - 10
Linux
VxWorks
LynxOS
Linux
Windows 2K, XP
32 MB
Bus Type
Option
PMC, PCI
/32MB
CPCI
/32MB
Note: Please contact Rastergraf for complete Model number
information.
1-24 General Information
Table 1-6 Eclipse3 Software
Rastergraf
Version
Software
DDX
3.0
GLDX
1.0
Xfree86
4.2
SDL
3.x
SDL
3.x
SDL
3.x
2K, XP
5.x
Table 1-7 Common Eclipse3 Configurations
DVI
Rear I/O
Option
Option
/DVI
n/a
/DVI
/RIO
OpenGL and/or
DirectX
no
OpenGL
OpenGL
no
no
no
OpenGL, DirectX
3U/6U
Local 3.3V
Option
Option
n/a
/V
/3U or /6U
n/a
DVI,
BIOS
SOG
yes
FCode
n/a
FCode
yes
VGA
yes
VGA
yes
VGA
yes
VGA
yes
VGA
Semi-rugged
Option
See Table 1-3
See Table 1-3
