1.2 Functional Description

As an aid to understanding the Eclipse3, a block diagram is provided at the
end of this section. The feature set includes:
• 128-bit Rastergraf Borealis 2D/3D Graphics Controller
• 33/66 MHz 32-bit PCI bus
• Embedded VGA controller
• Quad-Image BIOS supports FCode, VGA, DVI, and Sync-On-Green
• Up to 1920 x 1200 displayable analog resolution
• Up to 1280 x 1024 displayable digital (DVI) resolution
• Up to 32 MB high speed SGRAM supports multiple display pages
• Hardware pan, zoom, and scroll and bitmapped cursors
• Optional DVI Digital Output
• Non-interlaced, high refresh rate, and Sync-On-Green displays
• Optional three status LEDs (controlled by host software)
• Optional 2 Kb serial EEPROM
• Optional LM75 thermal sensor
• Optional 3.3V Regulator for systems without local 3.3V
• User selectable Sync-On-Green boot mode
• Two connector choices:
• Standard HD-15 VGA connector for RGBHV (only)
• DVI-I connector with RGBHV and DVI digital ports
• Three different PCB form factors:
• PMC single-wide module
• PCI (short)
• CompactPCI 3U board with either 3U or 6U faceplate
• Optional rear-panel I/O configuration for CompactPCI
• Ruggedized version (conformal coating and extended temperature)
• SDL Graphics Subroutine Package
• Sun/Solaris DDX 2D and 3D X Window System Servers
• Xfree86 Version 4.2 X Window System Server
• Windows 2K/XP drivers
1-2 General Information
