Rastergraf Eclipse3 Series User Manual page 60

Rastergraf
Note
Please read these sections before starting on this chapter:
Section 1.2
Chapter 2
This chapter includes the following other sections:
3.2
3.3
3.4
3.5
3.6
3.7
3.8
3.9
3.10 Flash EEPROM
3.11 Serial EEPROM
3.12 Interrupts
Because the Eclipse3 is mostly an assembly of "black box" parts, there
isn't a lot of external logic that has to be documented. Thus, the following
sections don't actually provide much programming information, as the
chip documentation and SDL device support cover that pretty well. The
sections summarize the devices and include some "hints and kinks".
You can refer to the Rastergraf web site for complete documentation.
You can also license the Rastergraf SDL source code itself.
The following sections assume that you have read Section I.2 and have
some knowledge of video, graphics, the PCI bus and the I
detailed information concerning operation of the PCI bus, please refer to
the Section 1.3, Additional References.
3-2 Programming On-board Devices
Functional description of the Eclipse3 boards.
Installation
Borealis Graphics Accelerator
Synchronous Graphics RAM (SGRAM)
Borealis Clocks
Video Timing Parameters
Eclipse3 Auxiliary Registers
System Management Devices
Talk to Me Through I
DVI Digital Video Output
2
C
2
C protocol. For
