Diagnostics Enabled

76
is used to evaluate the overall quality of the link between
Diagnostics
the handset, AP, and infrastructure side equipment, such as IP PBX,
SpectraLink 8000 SVP Server, and gateways. Unlike
is used while the functional code is running, and during a
Diagnostics
call.
When is enabled in the Admin menu, the handset can
Diagnostics
display diagnostic screens any time it is in active mode.
The display of information is instigated by pressing the
► key. Only four of the diagnostic counters listed below can be
Nav
shown at a time. Pressing the
through the various counters and the normal off-hook (IP-PBX)
display. The numeric icon at the top of the display indicates what
screen number is being displayed. For example: The first time the
key is pressed, the icon is shown, and the first four counters are
1
displayed. The next time it is pressed, the
next four counters are displayed. The counters will be cycled through
in this fashion until there are no more counters to be displayed. After
all the counters have been displayed, the screen returns to the normal
off-hook IP-PBX screen.
The information provided by
Screen 1
• Missed receive packet count since power up (MissedRcvCnt)
• Missed transmit packet count since power up (MissedXmtCnt)
• Receive retry count since power up (RxRetryCount)
•
Transmit retry count since power up (TxRetryCount)
M i s s e d R c v C n t
M i s s e d X m t C n t
R x R e t r y C o u n t
T x R e t r y C o u n t
keys multiple times will cycle
Nav
icon is shown, and the
2
includes:
Diagnostics
n n n n n
n n n n n
n n n n n
n n n n n
