Polycom SpectraLink 8020 Administration Manual page 90

SpectraLink 8020/8030 Wireless Telephone: Administration Guide for SIP
Message Description
Bad Config Some needed configuration parameter
has not been set.
Bad ESSID The handset is configured for "static
ESSID" (as opposed to "Learn once" or
"Learn always"), and no ESS ID has
been entered.
Bad Phintl File Handset software download files are
incorrect or corrupted.
Bad Program File Handset software download files are
incorrect or corrupted.
Bad SIP TFTP IP A bad unicast address has been
entered for the SIP TFTP server in
static entry mode.
(battery icon), Low battery.
Battery Low,
beep (audio)
Battery Failure The Battery Pack is not functioning.
Battery Failed Battery Pack is damaged or
incompatible with handset.
Can't Renew y...y = DHCP server IP address.
DHCP DHCP server is not responding to
yyy.yyy.yyy.yyy
initial renewal attempt.
Charging ... The handset is charging in the desktop
charger.
Charge Complete The handset is now fully charged.
Checking Code Handset is contacting the TFTP server
to determine if it has a newer version
of software that should be
downloaded.
90
Action
Check all required handset
configuration parameters for valid
settings.
Enter an ESSID in the configuration
settings or change to one of the "Learn"
modes.
Download new software from the
Polycom website per Software
Maintenance.
Download new software from the
Polycom website per Software
Maintenance.
Re-enter the correct IP address in the
administrative menus for static IP
addresses.
In call: the battery icon displays and a
soft beep will be heard when the user is
on the handset and the battery charge
is low. User has 15–30 minutes of
battery life left.
Not in call: The battery icon displays
whenever the battery charge is low The
message Battery Low and a beep
indicate a critically low battery charge
when user is not on the handset. The
handset will not work until the Battery
Pack is charged.
Replace the Battery Pack with a new or
confirmed SpectraLink Battery Pack.
Only SpectraLink Battery Packs will
work.
Replace the Battery Pack with a new or
confirmed SpectraLink Battery Pack.
Only SpectraLink Battery Packs will
work.
Configuration problem. Check the IP
address configuration in the DHCP
server.
No action needed.
No action needed.
None, this message should only last for
approximately one second. If message
remains displayed, power off and
contact customer support for a
replacement phone.
PN: 1725-36038-001_B.doc
