SpectraLink 8020/8030 Wireless Telephone: Administration Guide for SIP
System Diagram
access point
SpectraLink
Wireless Telephones
access point
optional
Wireless
POS
SpectraLink
Wireless Telephones
Supplied by
Polycom
12
The following diagram shows the Polycom components residing on a
network with APs and wireless LAN Ethernet Switch.
Handset code
TFTP server
Ethernet switch
SIP Server(s)
SIP proxy or SIP B2BUA
Ethernet cable
Phone cable
SIP config
SpectraLink 8000
internet
SVP Server
Optional SIP
Phones
PN: 1725-36038-001_B.doc
