Jan 1 00:01:26.72 0090.7a02.2a1b (172.16.0.46) [001a] RStat: AP 00:40:96:48:1D:0C (-56 dBm), Sent
783523, Recvd 791342, MSnt 245, MRcd 5674, BSnt 43, BRcd 10783, TX drop 43 (0.0%), TX retry 578
(1.2%), RX retry 1217 (1.6%)
PN: 1725-36038-001_B.doc
Audio stats
Audio error threshold exceeded
(Sent if payloads missed rate or
payloads late rate exceeds 2%, or if
the average jitter is over 2 msec)
Radio stats
Radio error threshold exceeded
(Sent if TX drop rate exceeds 2% or
TX or RX retry rate exceeds 5%)
Messages are formatted like the following example:
Diagnostic Tools
AP MAC
AP signal strength
Payload size (in msec)
Payloads sent
Payloads received
Payloads missed (not received)
Payloads missed rate (over last 5
seconds)
Payloads late
Payloads late rate (over last 5
seconds)
Average jitter
Same as audio stats
AP MAC
AP signal strength
Directed packets sent
Directed packets received
Multicast packets sent
Multicast packets received
Broadcast packets sent
Broadcast packets received
TX dropped count
TX drop rate (over last 5 seconds)
TX retry count
TX retry rate (over last 5 seconds)
RX retry count
RX retry rate (over last 5 seconds)
Same as radio stats
81
