Saving the
Configuration
Configuring the
Edge Router
Engine
Attaching a
Terminal to the
Console Port
To assign a carrier backplane port to a network using network management
software, use the following command:
set port slot.port network {ethernet_1 ... ethernet_8}
For example, the following command sets backplane port 1 (engine 1) in
the carrier installed in slot 3 to Ethernet_2:
ONcore> set port 3.1 network ethernet_2
Port 03.01 network id set to ETHERNET_2
To save configuration changes, use the SAVE command. For example, the
following command saves all configuration changes:
ONcore> save all
If you do not save module settings, you may lose configuration data.
Configure the Edge Router engine parameters using a management
terminal attached to either the console port or the auxiliary port.
This section includes the following topics:

Attaching a Terminal to the Console Port

Using the Terminal to Configure the Edge Router Engine
To attach a management terminal to the Edge Router module console or
auxiliary port:
1 Install the mini-DIN to DB-25 adapter cable into the circular connector
labeled "console" or "auxiliary" on the Edge Router module. Figure 3-1 shows
an example of how to connect the cable to the console port.

Configuring the Edge Router Engine

{isolated_1 ... isolated_4}
3-9
