A-6 A A: S
PPENDIX PECIFICATIONS
Console Port
Pinouts
This section describes:

Console Port Pinouts

Auxiliary Port Pinouts
DB-25 Null Modem Cable
Serial Port Pinouts
This section lists the cable pinouts for the:

DTE console port

Mini-DIN to DB-25 modem cable
DTE Console Port
Table A-9 lists pinouts for the console port on the Edge Router module.
Table A-9 Console Port Pinouts (DTE)
Pin Signal
1 DTR
2 Not Connected
3 TXD
4 GND
5 RXD
6 Not Connected
7 DCD
8 Not Connected
Input/Output
Output
Output
Input
Input
