5-2
C
5: T
HAPTER
ROUBLESHOOTING
Troubleshooting
Startup Problems
Troubleshooting
Router-Specific
Problems
Troubleshooting
Mailbox Interface
Problems
Troubleshooting
3Com Carrier
Problems
This section describes how to troubleshoot startup problems by monitoring
the LEDs on the Edge Router module.
This section describes:
Troubleshooting Router-Specific Problems
Troubleshooting Mailbox Interface Problems
Troubleshooting 3Com Carrier Problems
When you first install the Edge Router module in an ONline or ONcore hub
the Cisco engine runs a full set of hardware diagnostic tests. If the engine
fails diagnostics, the Router (RTR) LED does not illuminate or will flash. This
indicates a problem with the router hardware or software. Refer to the
appropriate Cisco Systems troubleshooting documentation for corrective
action.
ONline and ONcore Edge Routers use a hardware mailbox interface that
allows the Cisco engine to communicate with the 3Com carrier board
during powerup. If the 3Com mailbox does not establish communication
with the engine, the following message is reported to the engine console
port:
%MAILBOX-3-INITFAIL:Mailbox initialization failure.
Not getting interrupts. Mailbox offline.
If you see this message, contact your 3Com representative for assistance.
Before mailbox communication is initialized and established between the
Cisco engine and the 3Com carrier, the Module Status (S) LED on the front
panel of the Edge Router module blinks slowly. If communication is
established successfully, the Status LED illuminates and stays on solid. If the
Status LED does not light, the 3Com carrier board has malfunctioned.
Contact your 3Com representative for assistance. Refer to Appendix B for
instructions on contacting Technical Support for you product.
