4
Monitoring Edge
Router Module
Operation
M
ONITORING
M
ODULE
This chapter contains the following sections:

Monitoring Edge Router Module Operation

Showing Module Configuration and Status
The LEDs on the front panel of the Edge Router module allow you to
monitor the status of the module and ports. When you install the Edge
Router module in the hub:
1 The Router Status (RTR) LED is off if the router is booting (initializing).
2 The Router Status (RTR) LED illuminates once the router boot software is
running.
3 The Module Status (S) LED blinks while the module is attempting
communication with the carrier board.
4 The Module Status (S) LED stays illuminated once communication is
established with the carrier board.
Figure 4-1 shows the LED locations. Each LED indicates the state of the
module or port as described in Table 4-1.
E
DGE
O
PERATION
R
OUTER
