3-4 C 3: C
HAPTER ONFIGURING THE
Configuring the
Carrier in a
Managed ONline
Hub

Selecting a Network

Saving the
Configuration
E R M
DGE OUTER ODULE
This section describes how to use network management commands to
configure ONline carriers installed in an ONline System Concentrator. This
section contains the following topics:
Selecting a Network

Saving the Configuration

When you install the carrier in a hub with a management module installed,
the network defaults to isolated mode (Isolate_1). You must assign a
network as described below.
The engine connects to the backplane through a carrier module port on the
ONline carrier. You can assign the carrier module port to:
One of three Ethernet backplane networks
Isolated mode
For details on backplane networks, refer to the ONline System Concentrator
Installation and Operation Guide (Document Number 17-00417).
To assign the carrier module ports to a network using the network
management software, use the following command:
ONline> set port slot.port network
For example, the following command sets port 1 in the ONline carrier
installed in slot 3 to the Ethernet 2 backplane network:
ONline> set port 3.1 network ethernet_2
Port 03.01 network id set to ETHERNET_2
To save configuration changes, use the SAVE command. For example, the
following command saves all configuration changes:
ONline> save all
If you do not save module settings, you may lose configuration data.
{ethernet_1 ... _3}
{isolated_1}
