Showing Module
Configuration
and Status
Each LED is described in Table 4-1.
Table 4-1 Module LED Interpretations
LED Name
S
(Module Status)
RTR
(Router Status)
E0 Activity
(Ethernet Activity)
S0
(Serial Port 0 Activity)
S1
(Serial Port 1 Activity)
This section describes NMM commands that show module configuration
and status.
To show configuration and status for an Edge Router module, use the
following network management module commands:
SHOW MODULE
SHOW PORT

Showing Module Configuration and Status

Color State
Green Blinking
On
Green On
Off or Blinking
Yellow Blinking
Yellow Blinking
Yellow Blinking
4-3
Indicates
The module is in boot mode
and is attempting
communication with the
carrier board.
Remains lit as long as there
is active communication
with the carrier board.
Router is functioning
properly.
Router is not functioning.
Replace the module.
Traffic is being passed.
Traffic is being passed on
serial port 0.
Traffic is being passed on
serial port 1.
