If the NV SEL DIP switch is:
ON (enabled) – The Edge Router module uses configuration settings
stored in its NVRAM. If NVRAM does not contain configuration settings, the
Edge Router modules are assigned to the Isolate_1 network.
OFF (disabled) – The Edge Router module uses DIP switch settings.
Selecting a Network
In an unmanaged ONcore hub, the DIP switches determine the network
setting (unless NVRAM configuration settings are enabled).
1 To select a network:
Set the switches according to Table 2-5.
Table 2-5 ONcore Network Selection DIP Switch Settings
Switch Settings
Network
Selection
CH SEL 0
Ethernet_1
ON
(default)
Ethernet_2
OFF
Ethernet_3
ON
Ethernet_4
OFF
Ethernet_5
ON
Ethernet_6
OFF
Ethernet_7
ON
Ethernet_8
OFF
Isolate_1
ON
Isolate_2
OFF
Isolate_3
ON
Isolate_4
OFF
Switch combinations not listed in Table 2-5 select Isolate_1.
2 Disable NVRAM by setting the NV SEL DIP switch to the off position.
Configuring DIP Switches
CH SEL 1
CH SEL 2
CH SEL 3
ON
ON
ON
ON
ON
ON
OFF
ON
ON
OFF
ON
ON
ON
OFF
ON
ON
OFF
ON
OFF
OFF
ON
OFF
OFF
ON
ON
ON
OFF
ON
ON
OFF
OFF
ON
OFF
OFF
ON
OFF
2-11
