2-12 C 2: I
HAPTER NSTALLING THE
Installing the
ONline Edge
Router Module
E R M
DGE OUTER ODULE
This section describes how to install the ONline Edge Router module in an
ONline hub.
If you are installing:
An ONcore Edge Router module, refer to Installing the ONcore Edge Router
Module on page 2-13.
An ONline Edge Router module in an ONcore hub, refer to the ONcore
Switching Hub Installation and Operation Guide (Document Number
17-00362)
You do not need to power off the ONline hub to install or remove the Edge
Router module. You can insert the module while the hub is operating (this
is called a hot swap).
To install the Edge Router module in an ONline hub:
1 Use one of the following proper grounding techniques when you install the
Edge Router module:
Properly ground yourself prior to handling the module.
Attach a static wrist guard to yourself or touch a grounded static mat
prior to handling the module.
2 Locate an open slot in the ONline hub. If necessary, remove a blank panel
on the hub to expose a slot.
3 Insert the module into the slot's board guides and slide it into the hub by
pressing firmly at the top and bottom of the faceplate. Make sure the
connectors are well-seated into the backplane of the hub.
