3-8 C 3: C
HAPTER ONFIGURING THE
Determining the
Configuration
Source

Selecting a Network

E R M
DGE OUTER ODULE
Table 3-1 shows how to determine the carrier configuration source
.
Table 3-1 Determining the Carrier Configuration Source
DMM DIP
Hot Swap? Configuration
Yes Disable
Enable
‡
No Disable
Enable
* Use the SHOW DEVICE command to view the DIP configuration setting. Use the SET DEVICE
DIP_CONFIGURATION command to change the DIP configuration setting.
† If the carrier does not have configuration settings stored in NVRAM, it uses default settings.
If the DMM detects a problem with the NVRAM configuration, it forces the carrier to use
default settings. For example, if you install the carrier with ports assigned to Ethernet_8 into an
ONcore hub model that does not support Ethernet_8. If the configuration problem is port
level, the DMM forces only the affected ports to use default settings.
‡ The DMM must be fully initialized when you install the carrier module.
The Edge Router engine connects to an Ethernet network through a
backplane port on the ONcore carrier. A base engine installed in ONcore
carrier engine bay 1 uses carrier backplane port 1. A base engine installed in
ONcore carrier engine bay 2 uses carrier backplane port 5.
You can assign a carrier backplane port to:
One of eight Ethernet backplane networks
One of four Isolated backplane networks
For details on backplane networks, refer to the ONcore Switching Hub
Installation and Operation Guide (Document Number 17-00362-5).
NVRAM DIP Carrier
*
Switch Configuration Source
ON or OFF DMM passes the old
configuration settings to the
new carrier.
ON NVRAM settings
OFF DIP switch settings
ON NVRAM settings
OFF Default settings
ON NVRAM settings
OFF DIP switch settings
†
†
†
