4 Close the ejectors (Figure 2-6).

Figure 2-6 Opened and Closed Module Ejectors

5 Using your fingers, tighten the two spring-loaded screws on the front of the

Edge Router module faceplate (do not overtighten).

Installing the ONcore Edge Router Module

Opened

ejector

Closed

ejector

2-15
