A-4 A A: S
PPENDIX

Hub Capacities

ONline Hub
Capacities
ONcore Hub
Capacities
PECIFICATIONS
This section provides guidelines for installing Edge Router modules in
ONline or ONcore hubs.
Follow the guidelines in Table A-6 when installing ONline Edge Router
modules in an ONline System Concentrator.
.
Table A-6 ONline Module Restrictions
ONline System
Concentrator
17-Slot
Concentrator
6-Slot
Concentrator
Follow the guidelines in Table A-7 when installing ONcore Edge Router
modules in an ONcore 10-slot or 17-slot hub.
Table A-7 ONcore Hub Capacities for ONcore Modules
Number
of Power Slots
Supplies per Hub
1 10-Slot
17-Slot
2 10-Slot
17-Slot
3 10-Slot
17-Slot
4 10-Slot
17-Slot
Maximum Number
Model Power of Modules (both
Numbers (Watts) serial ports in use)
5017C 325 5
5006C 200 3
and
5006C-FT
Maximum Number of Modules
(fault-tolerant mode)
N/A
N/A
8
8
9
14
N/A
16
Maximum Number
of Modules (one
serial port in use)
10
6
Maximum Number of
Modules
(non-fault-tolerant mode)
8
8
9
14
9
16
N/A
16
