Edge Router Module
Console Port
Auxiliary
Port
High Speed
WAN Port
High Speed
WAN Port
Figure 1-1 Typical Edge Router Module Connections
The router module runs Cisco standard software and fully interoperates with
the:
3Com ONline Ethernet Router Module
Cisco local and remote router servers, such as the AGS+ , MGS , and the
Cisco 3000, 4000, 4500, and 7000 series routers.
Network
Backplane
Ethernet
LAN
