Telnet Commands (continued)
DEVICE STATUS
DIPSWITCH
DNS LIST
ECHO
encoder
Note: This command
must be entered in lower
case only.
EXIT
FACTORY APP
FACTORYFWIMAGE
FWIMAGES
Instruction Manual – DXLink™ Fiber Transmitters and Receivers, Duplex
Displays device status of a specified device, port, system (<D:P:S>).
Note: Devices other than the DXLink Fiber device itself will be ignored.
Example:
>device status 32002:1:0
Device Status
-------------
Device 32002 AMX LLC, DXLF-MFTX, 0.0.105.0 contains 8 Ports
Port 1 - Channels:255 Levels:8
MaxStringLen=64 Types=8 bit MaxCommandLen=64 Types=8 bit
The following input channels are on:None
The following output channels are on:None
Level 1=0 Supported data types=UByte,UInt
Level 2=0 Supported data types=UByte,UInt
Level 3=0 Supported data types=UByte,UInt
Level 4=0 Supported data types=UByte,UInt
Level 5=0 Supported data types=UByte,UInt
Level 6=0 Supported data types=UByte,UInt
Level 7=0 Supported data types=UByte,UInt
Level 8=0 Supported data types=UByte,UInt
Displays the current value for each of the DIP switch's four toggles.
Example:
>dipswitch
Board Switch Settings:
ON : ICS LAN Enabled
OFF : Reserved
ON : Network Enabled
OFF : Reserved
Displays list of DNS settings.
Example:
>dns list
DNS List
-------------
Domain suffix:
The following DNS IPs are configured
Entry 1:
Entry 2:
Note: This command applies only to the Transmitter.
Toggles echo of local characters on and off. Enter "echo on" or "echo off" or simply re-enter
"echo" to toggle between on and off.
Note: This command applies only to the Receiver.
Shows video encoder status.
Example:
>encoder
--------------------------------
Video Encoder (ADV7511)
TMDS On
Mute Unmuted
HDCP Screen No
Closes the current Telnet session.
Note: This command only applied to the Transmitter.
Resets the application to the factory image.
Note: This command does not reset the factory parameters.
Resets unit to factory firmware image and parameters and reboots the DXLink Fiber unit.
Note: When a Transmitter is connected to a DXLink Fiber Input Board, the input board will
override the "ALL RESOLUTIONS" EDID and load the last stored EDID.
Displays firmware version information.
Appendix B – Telnet (Terminal) Commands
amx.internal
192.168.40.7
192.168.40.8
