General Specifications (continued)
Noise Level
Airflow
Approvals
Other AMX Equipment
AMX Products Compatible with
DXLink Fiber Transmitters, Duplex
AMX Products Compatible with
DXLink Fiber Receivers, Duplex
Included Accessories
Compatible / Optional Equipment
Compatibility Note: In Enova DGX systems using duplex fiber technology – the DXLink Fiber Input Board
and its DXLink Fiber TX, Duplex must have the same type of fiber optic transceiver: either multimode or single
mode. The same holds true for DXLink Fiber Output Boards and the DXLink Fiber RX, Duplex units.
NetLinx and Control Specifications
ICS LAN / Ethernet Port
Serial Port
IR Control Port
Advanced Configuration Interface
ID Pushbutton
USB (HID) Keyboard and Mouse Specifications
USB (HID) TX
USB (HID) RX
Note: A list of HID devices which have been tested and found to be working well with the latest firmware is
available (see "DXLink - HID supported Devices" on the DXLink Fiber Receiver's product page).
AMX reserves the right to modify its products and their specifications without notice.
Instruction Manual – DXLink™ Fiber Transmitters and Receivers, Duplex
0 dBA @1m (typical), 45.3 dBA @ 1m (max)
Convection (openings on top of case, typical); forced air (out of front plate, when
fan is active).
UL 60950-1, CSA 60950-1, IEC 60950-1, CE EN 60950-1, CE EN 55022
Class A, CE EN 55024, FCC CFR Title 47 Part 15 Subpart B Class A, ICES-003
Class A, RoHS, WEEE
Enova DGX Digital Media Switchers
Enova DGX Digital Media Switchers
• Desktop power supply (ENERGY STAR
Caution: Only the provided desktop power supply should be used, and it
must not be altered in any way.
• CC-NIRC, NetLinx Emitter Cable (FG10-000-11)
• IR03, External IR Receiver Module (FG-IR03)
• CC-MINIUSB, Mini USB to PC cable adapter (FG5967-20): use with DXLink
Fiber RX only – for connecting a keyboard/mouse device
• CC-USB, USB programming cable (FG10-5965): use with DXLink Fiber TX
only – for connecting to a PC
• TCP/IP port (ICS LAN 10/100)
• RJ-45 connector
• Bidirectional RS-232
• Standard NetLinx baud rate 1200 to 115k
• Parity support: Odd/Even/None
• 3.5 mm pluggable Phoenix terminal block
• Port for use with IR03 External IR Receiver (optional accessory FG-IR03)
• Port for use with CC-NIRC NetLinx Emitter (optional accessory FG10-000-11)
USB mini-B connector (Program port)
• Toggle between DHCP and static IP addressing
• Places system in NetLinx Device ID assignment mode
• Reset the factory default settings
• Restore the factory firmware image
• (1) USB mini-A/B connector ("Host")
• Connect a DXLink Fiber TX to a PC and emulate keyboard and mouse
commands from a DXLink Fiber Receiver or a DXLink Twisted Pair Receiver
• (1) USB mini-A/B connector ("Device")
• Connect a keyboard and mouse and send commands to a PC connected to a
DXLink Fiber Transmitter or a DXLink Twisted Pair Transmitter
DXLink Fiber Specifications
®
qualified): 1 per unit
