Telnet Commands (continued)
SHOW DIGITAL STATS Note: This command applies only to the Transmitter.
SHOW DNS
SHOW LOG
SHOW MASTER
CONNECTION URL
SHOW NDP INFO
SHOW ROUTE
Instruction Manual – DXLink™ Fiber Transmitters and Receivers, Duplex
Displays information about the digital signal.
Example:
>show digital stats
Transmitter Video Signal
Video mode: HDMI
Upstream video is not freerun.
Is not 3D
1920 x 1200 5994 (Hz*100)
PClk: 15399 (MHz/10000) HFreq: 7403 (Hz*100), VIC: 0
HBlank: 48+33+79=160 HTotal: 2080
VBlank: 6+12+52=35 VTotal: 1235
Interlaced: False
Replication Factor: 1
Deep Color: 8 bits
Color Space: RGB 444
Video is not encrypted.
Shows the DNS settings.
Example:
>show dns
DNS Servers
------------------------------------------
Domain suffix:
Entry 1:
Entry 2:
Displays the message log.
Syntax:
SHOW LOG <start>
• Use <start> to specify the message number to start displaying.
• Use <all> to display all messages.
Shows Master connection information.
Example:
>show master connection url
Master Connection URL
------------------------------------------
Master IP/URL:
Master Port:
Displays NDP information.
Example:
>show ndp info
Stored Parameters:
Master Connection Mode
MAC Address for bound Master
Current Parameters:
Current NDP state is
Number of announcements
Current Master IP Address
Shows all active network routes the device detects.
Example:
>show route
Active Routes
------------------------------------------
Network
0.0.0.0
127.0.0.0
192.168.43.0 255.255.255.0
Appendix B – Telnet (Terminal) Commands
amx.internal
192.168.40.7
192.168.40.8
192.168.1.91
1319
: NDP
: 00:60:9f:94:94:1f
: NdpFound
: 2
: 192.168.43.52
Netmask Gateway
0.0.0.0 192.168.43.2
255.0.0.0 127.0.0.1
127.0.0.1
