HDMI Specifications
Compatible Formats
Signal Type Support
Video Data Rate (max.)
Video Pixel Clock (max.)
Progressive Resolution Support
Interlaced Resolution Support
Deep Color Support
Color Space Support
3D Format Support
Audio Format Support
Audio Resolution
Audio Sample Rate
Local Audio Support
HDCP Support
CEC support
^ Only supported when the DXLink Fiber HDMI RX scaler is in Bypass Mode using CEA-861 formats and the resolution is
1080p60 or less.
^^ Input signal support for YCbCr 4:4:4 and 4:2:2; output color-space is converted to RGB 4:4:4.
^^^ The Scaler on corresponding output board must be set to Bypass Mode.
* Dolby Digital and DTS support up to 48 kHz, 5.1 channels.
Note: Interlaced and progressive video are supported into the Transmitter; progressive is only supported out
of the Receiver unless in non-scaling Bypass Mode.
AMX reserves the right to modify its products and their specifications without notice.
Instruction Manual – DXLink™ Fiber Transmitters and Receivers, Duplex
HDMI, HDCP, DVI (DVI requires conversion cable)
• HDMI
• DVI-D (Single Link via a DVI-to-HDMI cable adapter)
• DisplayPort++ (input only with HDMI or DVI cable adapter)
4.95 Gbps / 5.568 Gbps^
165 MHz / 185.625 MHz^
480p up to 1920x1200 @ 60 Hz (supported resolutions are listed in the "Supported
Input Resolutions" appendix; see page 119)
480i, 576i, 1080i (supported resolutions are listed in the "Supported Input
Resolutions" appendix; see page 119)
24 bit, 30 bit^
RGB 4:4:4
YCbCr^^ 4:4:4 and 4:2:2
Yes^^^ (HDMI Primary Formats)
• Frame Packing 1080p up to 24 Hz
• Frame Packing 720p up to 50/60 Hz
• Frame Packing 1080i up to 50/60 Hz
• Top-Bottom 1080p up to 24 Hz
• Top-Bottom 720p up to 50/60 Hz
• Side-by-Side Half 1080i up to 50/60 Hz
Dolby TrueHD, Dolby Digital*, DTS-HD Master Audio, DTS*, 2 CH L-PCM,
6 CH L-PCM, 8 CH L-PCM
16 bit to 24 bit
32 kHz, 44.1 kHz, 48 kHz, 96 kHz, 192 kHz
TX insertion, RX extraction
Yes
• Supports AMX HDCP InstaGate Pro
• When used with an Enova DGX Digital Media Switcher, the key support is up to
16 sinks per output, independent of the source device.
CEC is not currently supported
DXLink Fiber Specifications
®
Technology.
