CHANNELs

Important: Before DXLink Fiber Transmitters and Receivers can receive any NetLinx SEND_COMMANDs,
the DIP switch's #3 Toggle must be set to ON or the devices will not be accessible from a NetLinx control
system.
Note: Since not all devices support both upper and lower case, for best results all commands and parameters
should be sent in upper case.

DXLink Fiber Receiver Video SEND_COMMANDs

DXLink Fiber Receiver Video SEND_COMMANDs are sent to Port 6.
Note: Asynchronous notifications are not available for the Receivers via NetLinx Studio (and Telnet).
Video SEND_COMMANDs (Receivers)
Command
?VIDOUT_SCALE
Requests the current Scaling Mode
that the Receiver is set to. The modes
are AUTO (SmartScale
and BYPASS.
VIDOUT_SCALE
VIDOUT_SCALE
Scaling Modes
Sets the Scaling Mode on the Receiver
to AUTO (SmartScale
BYPASS.
?VIDOUT_RES_REF
Requests the resolution and refresh
rate of the video through the Receiver.
Note: If the Scaling Mode is set to
Bypass, the response will be
"BYPASS."
VIDOUT_RES_REF
Sets the resolution and refresh rate of
the video through the Receiver.
Important: The "valid responses"
values used must come from the
Resolution Names listed in the table in
the "Supported Output Resolutions"
appendix on page 122.
Note: The default for Manual Mode is
1280x1024,60.
Instruction Manual – DXLink™ Fiber Transmitters and Receivers, Duplex
Channel Function
255 This channel On indicates that the DXLink Fiber unit has a valid UTP (twisted pair cable)
connection to a switcher with an integrated Master.
If the channel is Off, the DXLink Fiber unit is incorrectly connected.
1-253 Key presses from selected remote control.
Description
Syntax:
SEND_COMMAND <DEV>,"'?VIDOUT_SCALE'"
Example:
®
), MANUAL,
SEND_COMMAND dvRX,"'?VIDOUT_SCALE'"
VIDOUT_SCALE-<AUTO/MANUAL/BYPASS>
Syntax:
SEND_COMMAND <DEV>,"'VIDOUT_SCALE-<scaling mode>'"
®
Valid responses:
), MANUAL, or
Example:
SEND_COMMAND dvRX,"'VIDOUT_SCALE-MANUAL'"
Syntax:
SEND_COMMAND <DEV>,"'?VIDOUT_RES_REF'"
Valid responses:
• horizontal = An integer value representing the horizontal.
• vertical = An integer value representing the vertical. May have an
• rate = An integer value representing the refresh rate.
Example:
SEND_COMMAND dvRX,"'?VIDOUT_RES_REF'"
VIDOUT_RES_REF-<horizontal>x<vertical>,<rate>
Syntax:
SEND_COMMAND <DEV>,"'VIDOUT_RES_REF-
<horizontal>x<vertical>,<rate>'"
Valid responses:
• horizontal = An integer value representing the horizontal.
• vertical = An integer value representing the vertical. May have an
• rate = An integer value representing the refresh rate.
Example:
SEND_COMMAND dvRX,"'VIDOUT_RES_REF-1920x1080p,60'"
NetLinx Programming – DXLink Fiber TXs/RXs
Returns a COMMAND of the form:
scaling mode = AUTO, MANUAL, BYPASS
additional qualifier such as "p" or "i".
Returns a COMMAND of the form:
additional qualifier such as "p" or "i".
68
