In a system where DXLink Fiber Transmitters and Receivers are used in conjunction with an Enova DGX 8/16/32/64,
Example
the cable runs from a Transmitter to a DXLink Fiber Input Board and from a DXLink Fiber Output Board to a Receiver
Endpoint/
depend on the quality of the cable (see cable specifications on page 28).
Bidirectional
Modes
DXLink Fiber
Input Board
DXLink Fiber Transmitter
FIG. 9
Endpoint Mode (Switcher) setup with Enova DGX 16
Tip: For systems with special requirements – Before installing in the final location, place the equipment close
together, so that the destination monitor and a PC for control can be seen simultaneously if adjustments are
necessary. Scaling adjustments can be made using SEND_COMMANDs (see page 66). For Enova DGX
Digital Media Switcher systems, DGX Configuration Software can also be used to make scaling adjustments
via the switcher (see the switcher's "Instruction Manual").
Custom EDID Settings
If your system has special EDID requirements, see page 130 for information on managing and programming custom
EDIDs.
Options for System Setup with Enova DGX DXLink Fiber Boards
The following table contains options for using DXLink Fiber Transmitters and Receivers in conjunction with DXLink
Fiber Input and Output Boards in an Enova DGX Digital Media Switcher.
System Setup Options - Enova DGX DXLink Fiber Boards with DXLink Fiber TXs and RXs
DXLink Fiber TX
SMF-D TX
SMF-D TX
SMF-D TX
MMF-D TX
MMF-D TX
MMF-D TX
Not applicable
Not applicable
Instruction Manual – DXLink Fiber™ Transmitters and Receivers, Duplex
Source device
Enova DGX Input Board

DXLink Fiber SMF-D

DXLink Fiber SMF-D

DXLink Fiber SMF-D

DXLink Fiber MMF-D

DXLink Fiber MMF-D

DXLink Fiber MMF-D
Any board
Any board
AC
AC
DC
DC
F L T
F L T
Fiber optic cable
Enova DGX Output Board

DXLink Fiber SMF-D

DXLink Fiber MMF-D

Any board

DXLink Fiber MMF-D

DXLink Fiber SMF-D

Any board

DXLink Fiber SMF-D

DXLink Fiber MMF-D
Installation and Setup
DXLink Fiber
Output Board
DXLink Fiber Receiver
Destination device
DXLink Fiber RX

SMF-D RX

MMF-D RX

Not applicable

MMF-D RX

SMF-D RX

Not applicable

SMF-D RX

MMF-D RX
