Appendix F – Supported Output Resolutions

HDMI and DVI Supported Output Resolutions

The resolutions in the following table are supported on the DXLink Fiber RX and can be set using a
SEND_COMMAND. The horizontal/vertical/refresh information from the Resolution Name (in the first column)
can be entered in a SEND_COMMAND command (VIDOUT_RES_REF) to specify scaling parameters for the DXLink
Fiber RX. For complete command information, see page 66.
Note: The resolutions and timings in the table below can only be changed with SEND_COMMANDs.
HDMI and DVI Supported Output Resolutions
Resolution Name
640x480@60
640x480@72
640x480@75
800x600@60
800x600@72
800x600@75
1024x768@60
1024x768@70
1024x768@75
1280x720p@50
1280x720p@60
1280x768@60
1280x800@60
1280x1024@60
1360x768@60
1440x900@60
1600x1200@60
1680x1050@60
1920x1080@60
1920x1080p@50
1920x1080p@60
1920x1200@60
Instruction Manual – DXLink™ Fiber Transmitters and Receivers, Duplex
Horizontal Vertical Active
Active Pixels Pixels
640 480
640 480
640 480
800 600
800 600
800 600
1024 768
1024 768
1024 768
1280 720
1280 720
1280 768
1280 800
1280 1024
1360 768
1440 900
1600 1200
1680 1050
1920 1080
1920 1080
1920 1080
1920 1200
Appendix F – Supported Output Resolutions
Refresh (Hz) Comments
60
72
75
60
72
75
60
70
75
50 720p
60 720p
60
60
60
60
60
60
60
60 1080
50 1080p
60 1080p
60 Reduced
Blanking
Video Standard
VESA DMT
VESA DMT
VESA DMT
VESA DMT
VESA DMT
VESA DMT
VESA DMT
VESA DMT
VESA DMT
CEA 861
CEA 861
VESA CVT
VESA DMT
VESA DMT
VESA CVT
VESA DMT
VESA CVT
VESA CVT
CEA 861
CEA 861
VESA CVT-R
122
