HDMI Specifications (continued)
DXLink Fiber TX
Input Signal Type
Local Loopback Output
Local Loopback Output
+5 V DDC Pin
DDC/EDID Support
Input Voltage (nominal)
Input Re-clocking (CDR)
Input Equalization
Input Connector
Local Loopback
Output Connector
Propagation Delay (typical)
DXLink Fiber RX
Output Signal Type
Output Scaling
SmartScale
Support
Output Nominal Voltage
Output Re-clocking
+5 V DDC Pin Output
+5 V USB Output
Output Rise Time / Fall Time
Output Connector
Propagation Delay (typical)
HDMI Audio Synchronization
AMX reserves the right to modify its products and their specifications without notice.
Instruction Manual – DXLink™ Fiber Transmitters and Receivers, Duplex
• HDMI
• DVI-D (Single Link with a DVI-to-HDMI cable adapter)
• DisplayPort ++ (input only with HDMI cable adapter)
DVI-D, non-scaling (Single Link with cable adapter)
55 mA
• When the TX is connected to an Enova DGX Digital Media Switcher, the HDMI and
VGA EDIDs are synchronized with the persisted EDIDs on the DXLink Fiber Input
Board and are user re-programmable.
• For the specific EDID list, see the specifications in the "Enova DGX DXLink Fiber
Boards" chapter in the Installation Manual – Enova DGX 8/16/32/64.
1.0 Vpp differential
Yes
Yes, adaptive
HDMI Type A female
HDMI Type A female
4.8 μs
• HDMI
• DVI-D (Single Link with cable adapter)
SmartScale
®
Output Resolution All resolutions between 480p and 1920x1200 @ 60 Hz via automatic SmartScale
query of the display's preferred EDID detailed timing definition.
1.0 Vpp differential
Yes
55 mA
500 mA
425 ps typical (20% to 80%)
HDMI Type A female
26 ms when scaling; 5.2 μs when in Bypass Mode
Video formats @ 60 Hz frame rate: in Scaling Mode, audio leads video by 12 ms
typical (4 ms to 20 ms). In Bypass Mode, audio lags video by 17 ms.
®
, Manual Configuration, Bypass
DXLink Fiber Specifications
®
