Introduction
Introduction, cont'd
The Extron RCP 2000 remote control panel provides complete
remote control of a seamless switcher. The RCP controls the
input selection, transition effect (cut, dissolve, or wipe),
transition duration (automatic or T-bar manual control), and
picture controls (color, tint, contrast, brightness, sizing, and
centering) that are available on the ISS 108/408 or SGS 408
seamless switcher.
The RCP 2000 offers bi-directional Ethernet communication for
the ISS 108/408, and RS-232 communication for both the ISS
and the SGS 408. The RCP 2000 allows a switch to occur from
either the RCP or the seamless switcher while the other device is
being updated.

Features

Comprehensive picture controls — Enable you to adjust the
following:
Contrast/Brightness — Adjusts the light intensity and the
range of dark and light values of the output.
Centering and sizing — Allow the output to be centered
or sized, both horizontally and vertically.
Detail — Adjusts the level of picture sharpness.
Color/Tint — Adjusts the intensity and appearance of the
picture colors.
Remote operation — Allow seamless switchers to be operated
remotely via Ethernet (Internet or intranet) or RS-232.
Program and preview inputs — Allow you to select the
upcoming switch.
Transition controls (Cut, Dissolve, Wipe, and Take) — Control
the type of switch that will occur between the preview
and program outputs. See Applying and Changing a
Switching Effect in chapter 3 for descriptions of the
transitions controlled by these buttons.
Freeze and Black buttons — Allow you to freeze or blank any
input on either the program or the preview.
RCP 2000 • Introduction
1-2
