Installation, cont'd
• When connecting the RCP 2000 directly (no intermediate
device present, such as a network hub) to the ISS 108/408,
you must use a crossover cable. See the table on the next
page for RJ-45 crossover cable connections.
RJ-45 Ethernet Crossover Cable
RCP 2000 end
Pin Wire color
1 White-orange Transmit +
2 Orange
Transmit -
3 White-green Receive +
Receive -
6 Green
N/A
4 Blue
5 White-blue N/A
7 White-brown
8 Brown
N/A
• When connecting the RCP 2000 indirectly (intermediate
device present, such as a network hub) to the ISS 108/408,
you must use a patch (straight-through) cable. See the
table below for RJ-45 patch cable connections.
RJ-45 Ethernet Patch Cable
RCP 2000 end
Pin Wire color
1 White-orange Transmit +
2 Orange Transmit -
3 White-green Receive +
4 Blue N/A
N/A
5 White-blue
6 Green Receive -
7 White-brown N/A
8 Brown N/A
2-6 RCP 2000 • Installation
Intermediate hub, etc., end
Signal Signal
Pin Wire color
3 White-orange Receive +
6
Orange Receive -
1 White-green Transmit +
Transmit -
2 Green
N/A
4 Blue
5 White-blue N/A
N/A N/A
7 White-brown
Brown
8 N/A
SGS 408, ISS 108/408 end
Signal Pin Signal
Wire color
1 White-orange Receive +
2
Orange Receive -
3 White-green Transmit +
4 Blue N/A
5 N/A
White-blue
6 Green Transmit -
7 White-brown N/A
8 Brown N/A
