Remote Control, cont'd
Figure 4-7— ISS Control screen

Using network switcher control

To use network switcher control, follow these steps:
1. Set the level of control desired: video/audio, video only, or
audio only.
2. Select the Program (output) that you want to switch.
3. Select the Preview (input) that you want to switch to.
4. Set the parameters of the switch (for example, Dissolve
Speed or RGB Delay), and click the appropriate button to
execute the switch (e.g., Cut, Dissolve, etc.).
- OR-
Click the button for the desired effect (for example,
Black/Mute, Freeze, Test Pattern, or Blue Screen Mode) for
the output.
To compare Program (output) and Preview (input) scan
rates, click View Program (or Preview) Scan Rate.
If you require a test pattern on either the Program or the
Preview, select the desired test pattern from the drop-
down menu; and select either the Program or the
Preview check box in the Test Pattern section of the
screen.
For a more complete description of seamless switching and the
options available for each switcher, refer to the user's manual
for your specific switcher.
4-10 RCP 2000 • Remote Control
RCP 2000 Remote Control Panel
A
Specifications, Parts, and
Appendix
Accessories

Specifications

Part Numbers
