User's Guide
The RCP 2000 will work with an ISS 108 or ISS 408 that has firmware version 1.01 or later.
Check the firmware installed in your ISS switcher. If the installed firmware is version is 1.0 or
earlier, install the firmware chips that are attached to this sheet.
Check the ISS's Firmware level
Apply power to the ISS. During the power up process, the switcher displays the model name,
part number, and the firmware version in its LCD display (figure 1).
Extron Electronics
Power
on Integration
Seamless Switcher
Figure 1 — Identifying the firmware version
Replace the ISS's Firmware
1.
CAUTION
2.
3.
4.
5.
CAUTION
6.
7.
8.
www.camboard.de
CAMBOARD Electronics
Extron Electronics
ISS 408 ISS 408
60-423-01
2
sec.
Version x . xx
Version 1.00 or earlier, Version 1.01 or later,
you must replace the you do not need to
firmware. replace the firmware.
Disconnect the AC power cord from the ISS to remove power from the unit.
To prevent electric shock, always unplug the ISS from the AC power source before
opening the enclosure.
Changes to firmware must be performed by authorized service personnel only.
If the ISS is installed in a rack, disconnect all signal and control cables and remove the ISS
from the rack.
Remove the 16 screws, 8 on the top and 4 on each side of the ISS cover (figure 2 on the
opposite side of this guide).
Remove the top two front panel screws.
Lift the top cover straight up approximately five inches until you can access the fan power
cords.
Do not touch any switches or other electronic components inside the ISS. Doing so
could damage the switcher. Electrostatic discharge (ESD) can damage IC chips even
though you cannot feel it. You must be electrically grounded before proceeding with
firmware replacement. A grounding wrist strap is recommended.
Disconnect the two fan power cords from connectors J8 and J13 on the main board.
Lift the top cover out of the way.
Locate firmware chip U6 on the front panel circuit board and chips U98, U99, U100, and
U101 on the main circuit board (figure 2).
Tel. 07131 911201
Fax 07131 911203
Default Display Cycle
Program #1 RGB
0.00 kHz 0.00Hz
2 Preview #3 S-Video
sec.
0.00 kHz 0.00Hz
ce-info@camboard.de
Output Rate
2 1280 x 1024 @ 60
sec.
2
sec.
68-575-02 Rev. A
