Specifications, Parts, and Accessories
Specifications, Parts, and Accessories, cont'd
Specifications
Control/remote — control panel
Serial control port ........................ RS-232, 9-pin female D connector
Baud rate and protocol ............... 9600, 8-bit, 1 stop bit, no parity
Serial control pin configurations 2 = TX, 3 = RX, 5 = GND
Ethernet control port ................... 1 RJ-45 female connector
Ethernet data rate ........................ 10/100Base-T, half/full duplex with
autodetect
Ethernet protocol ......................... ICMP (ping), TCP/IP, Telnet
Program control ........................... Extron's control program for Windows®,
Extron's Simple Instruction Set™ – SIS™,
Microsoft Explorer, Telnet
General
Power ............................................. 100 VAC to 240 VAC, 50/60 Hz, 60 watts,
internal, autoswitchable
Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) /
10% to 90%, non-condensing
Operating +32° to +122°F (0° to +50°C) /
10% to 90%, non-condensing
Rack mount ................................... No
Enclosure type .............................. Metal
Enclosure dimensions ................. 5.25" H x 16" W x 11.5" D
13.3 cm H x 40.6 cm W x 29.2 cm D
(Depth excludes connectors and knobs.)
Product weight ............................. 15 lbs (6.8 kg)
Shipping weight .......................... 22 lbs (10 kg)
Vibration ....................................... ISTA/NSTA 1A in carton (International
Safe Transit Association)
Listings .......................................... UL, CUL
Compliances ................................. CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
Specifications are subject to change without notice.
A-2 RCP 2000 • Specifications, Parts, and Accessories
Part Numbers
Extron Part
RCP 2000
RS-232 male-male cable – 2' (.61 m)
RS-232 male-male cable – 4' (1.22 m)
RS-232 male-male cable – 25' (7.6 m)
RS-232 male-male cable – 50' (15.2 m)
RS-232 male-male cable – 100' (30.5 m)
RS-232 male-male cable – 250' (76.2 m)
RCP 2000 User's Manual
RCP 2000 • Specifications, Parts, and Accessories
Part Number
60-571-01
26-434-01
26-434-02
26-434-07
26-434-08
26-434-10
26-434-13
A-3
